Configured for high-speed network routing and slot interconnection within AC500 V3 platforms, the ABB TB5610-2ETH 1SAP111300R0278 (TB5610-2ETH Terminal base) provides direct physical/electrical execution.

Architectural Suffix & Hardware Breakdown

• TB5610-2ETH: Core designation denoting AC500 V3 terminal base architecture with dual Ethernet routing support.
• 1SAP111300R0278: Official manufacturing order code assigned for component stocking and exact replacement tracking.
• AC500 V3 Compatibility: Tailored interface matrix designed to support modern third-generation processor and communication modules.
• Multi-Interface Slot: Integrates 2 Ethernet ports, 1 serial interface, and 1 CAN communication slot (TB5610-2ETH configuration).

Hardware Specifications

Deterministic Network Execution & Bus Integration

The terminal base ensures high-speed backplane bus communication velocity Licences across connected processor and I/O expansion tiers. Integrated support for Profinet and EtherNet/IP deterministic networks enables seamless packet routing, while firmware flash compatibility on mated CPUs allows instant parameter synchronization without signal distortion.

Delivery Package Contents

• 1 x ABB TB5610-2ETH (1SAP111300R0278) Terminal Base
• 1 x Anti-Static Protective Enclosure
• 1 x Terminal Wiring Reference Guide

Physical Mounting & Wiring Instructions

DIN-Rail Installation Procedures

• Snap the modular base securely onto a standard 35 mm DIN rail inside an IP54 rated control panel enclosure.
• Maintain minimum clearance clearances around top and bottom cable channels to allow unhindered thermal air convection.

Spring-Clamp Field Termination Guidelines

• Strip field wires to a length of 8 mm and insert them directly into the 24 spring-clamp terminals rated for 0.08 to 2.5 mm squared conductors.
• Ensure incoming 24 VDC power and communication cable shields are properly bonded to the panel ground bar to suppress electromagnetic interference.

Frequently Asked Questions

• Is the TB5610-2ETH base module hot-swappable under power?

  No, power must be completely isolated from the 24 VDC supply before inserting or extracting mounted CPU or communication modules.

• What voltage range is supported on the incoming power distribution lines?

  The terminal base distributes standard 24 VDC control power across the backplane bus for connected processor units.

• How many communication modules can be plugged into this specific base?

  The hardware layout provides a dedicated single slot for one communication module alongside dual onboard Ethernet ports.

• What conductor cross-section size fits the spring-clamp terminals?

  The 24 spring-clamp field wiring points accommodate solid and stranded wire dimensions ranging from 0.08 to 2.5 mm squared.

• What level of electrical isolation protects the communication channels?

  The internal circuit architecture provides 1500 VAC isolation to safeguard against transient line surges and ground loops.

• What are the extreme ambient operating temperature limits?

  The base module functions continuously within an ambient temperature range spanning from -25 deg C to +60 deg C.

• What relative humidity conditions can the unit withstand?

  The system operates reliably in non-condensing relative humidity environments between 5% and 95% RH.

• What protocol interfaces are available directly on the terminal base?

  The unit features 2 Ethernet interfaces, 1 serial interface, and 1 integrated CAN interface channel.
