1756-A4 Allen-Bradley ControlLogix Chassis

Allen-Bradley 1756-A4 Chassis ControlLogix

Allen-Bradley

Allen-Bradley 1756-A4 Chassis ControlLogix

SKU: 1756-A4

In Stock

Dimensions: 21.2 x 26.8 x 16.8 cm
Country of origin: USA
Payment: T/T, Western Union
Shipping port: Xiamen

Categories : All Products, Allen-Bradley, Allen-Bradley ControlLogix & CompactLogix

Tags : Allen-Bradley ControlLogix, Allen-Bradley GuardLogix, Chassis Racks, Communication Modules

1 years warranty

Delivery time: 3-7 business days

Free 30 days return

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Allen-Bradley 1756-A4, also cataloged as the 1756A4 Chassis, operates as a dedicated hardware component for physical module mounting and backplane signal distribution within ControlLogix networks.

Part Number Breakdown & Module Matrix

1756: Base product family identifier designating Allen-Bradley ControlLogix hardware platforms.
A4: Chassis configuration suffix specifying a four-slot horizontal physical backplane layout.

Hardware Specifications

Parameter	Specification
Model	1756-A4
Brand	Allen-Bradley
Origin	USA
Weight	1.05 kg
Shipping Dimensions	21.2 x 26.8 x 16.8 cm
Operating Temp	0 deg C to 60 deg C
Power Consumption	4 Watts max dissipation
Slots	Four (4) slots
Mounting	Horizontal
Backplane Current (5 VDC)	10 A
Backplane Current (24 VDC)	2.8 A

Industrial Control & Drive Interface Integration

Engineered for industrial automation environments, the chassis facilitates high-speed backplane bus communication velocities and supports Profinet and EtherNet/IP deterministic networks. It guarantees precise I/O density scaling and firmware flash compatibility across installed controller modules.

Package Ordering Information

1 x 1756-A4 ControlLogix 4 Slots Chassis unit
1 x Grounding mounting screw kit

Mechanical Installation Guidelines

Panel Mounting: Secure the chassis firmly to a grounded metal backplate using all designated mounting holes to withstand operational vibration.
Grounding Compliance: Connect the chassis ground lug directly to the enclosure ground bus using a low-impedance copper conductor.
Thermal Clearance: Maintain minimum vertical and horizontal spacing around the chassis housing to allow unimpeded convective airflow.

Frequently Asked Questions

Q: What is the total slot capacity of the 1756-A4 chassis?

A: The unit provides a total of four physical backplane slots for module installation.
Q: What is the maximum power dissipation rating for this backplane?

A: The maximum power dissipation capacity of the chassis backplane is 4 Watts.
Q: How much 5 VDC backplane current is available for connected modules?

A: The chassis supplies up to 10 amps of current on the 5 Volts DC backplane rail.
Q: What is the maximum 24 VDC backplane current output?

A: The backplane delivers a maximum current of 2.8 Amps on the 24 Volts DC rail.
Q: What is the official physical weight of the chassis unit?

A: The unboxed hardware unit weighs 1.05 kg with estimated shipping dimensions of 21.2 x 26.8 x 16.8 cm.
Q: What country is designated as the origin of manufacture?

A: The hardware unit is manufactured in the USA.
Q: Can modules be inserted or removed while power is applied?

A: ControlLogix backplanes support removal and insertion under power (RIUP) for compatible modules, provided proper precautions are followed.
Q: What mounting orientation is specified for this chassis?

A: The chassis is designed strictly for horizontal panel mounting configurations.
