Product Overview

The Honeywell MC-PDOY22 (Part Number 80363975-150) is a high-density discrete interface module engineered for the Experion® Series C I/O environment. This module provides 32 independent digital output channels, allowing a single slot in the DCS rack to manage a wide array of field-level binary devices. Designed for precision and reliability, the MC-PDOY22 utilizes Form C dry contact relay outputs, making it highly adaptable for switching various signal types without requiring complex interposing hardware for low-power applications.

As a core component of the Series C architecture, this module is built to provide maximum signal density in a compact footprint. It effectively bridges the gap between the C300 controller logic and physical equipment such as solenoids, indicators, and motor starters. Its design emphasizes electrical safety and system integrity, ensuring that high-voltage transients on the field side do not migrate to the sensitive control network.

Hardware Parameters and Technical Characteristics

The MC-PDOY22 is built to rigorous industrial standards, featuring high-grade isolation and a robust mechanical design for long-term service.

• Channel Density: 32 Independent Output Channels

• Output Type: Form C Dry Contact Relays (Normally Open / Normally Closed)

• Nominal Switching Voltage: 24V DC

• Current Rating: 0.5 Amperes per channel (Maximum)

• Isolation Protection: 1500V Galvanic isolation between channels and power supply

• System Integration: Fully compatible with Honeywell Experion® Series C I/O racks

• Mounting Interface: Standard DIN rail mounting via compatible IOTA

• Diagnostic Indicators: On-board status LEDs for rapid visual troubleshooting of channel activity

• Power Supply: Low-power consumption design optimized for Series C power systems

• Weight: 0.4 kg

• Dimensions: 7 x 14 x 14.5 cm

• Origin: USA

Industrial Applications

The 32-channel capacity of the MC-PDOY22 makes it the preferred choice for facilities requiring extensive discrete control:

• Petrochemical Refining: Managing a large number of solenoid-operated valves (SOVs) for process sequencing and safety interlocks.

• Power Plant Automation: Driving status annunciators, alarm horns, and small auxiliary relays within turbine and boiler control rooms.

• Water Treatment Systems: Coordinating the start/stop signals for a distributed network of pumps and chemical feeders.

• Batch Manufacturing: Executing complex discrete logic for multi-stage production lines in the food, beverage, and pharmaceutical industries.

• Building Automation: Controlling HVAC dampers and security lighting through centralized DCS logic.
