Product Overview

The Allen-Bradley 80190-100-01-R is a high-speed fiber optic interface board designed for the legacy PLC-5 platform and associated control systems. This module serves as a specialized communication bridge, enabling the transmission of control data over optical fiber rather than traditional copper media. By utilizing light signals, the 80190-100-01-R provides total immunity to electromagnetic interference (EMI) and radio frequency interference (RFI), making it an essential component for distributed I/O networks in electrically noisy industrial environments. Its lightweight, compact design allows for easy integration into existing PLC-5 chassis or specialized control assemblies, ensuring long-distance signal integrity without the risk of ground loops.

Technical Characteristics

The 80190-100-01-R is engineered to maintain high-speed deterministic communication in the most challenging industrial settings:

Superior Noise Immunity and Isolation The primary benefit of this fiber optic board is its ability to operate in environments with heavy machinery, high-voltage equipment, and variable frequency drives (VFDs). Because the medium is non-conductive, it provides complete electrical isolation between nodes, protecting the PLC-5 CPU from voltage surges and lightning strikes.

Extended Distance Capabilities Unlike standard copper-based DH+ or Remote I/O links that suffer from signal attenuation over long distances, this fiber optic board allows for significantly extended network segments. This capability is vital for large-scale facilities, such as automotive assembly lines or expansive energy refineries, where control stations are separated by hundreds of meters.

Advanced Real-Time Diagnostics The board features integrated status monitoring to assist maintenance teams in quickly identifying link failures. By providing immediate feedback on signal strength and connectivity, it facilitates a proactive maintenance approach, reducing mean time to repair (MTTR) and preventing unplanned system downtime.

Ruggedized for Extreme Environments Built to withstand the rigors of the factory floor, the 80190-100-01-R is resilient against vibration, shock, and thermal fluctuations. Its high-quality USA-based manufacturing ensures that the optical transceivers remain aligned and functional even in high-vibration machinery applications.

Technical Specifications

• Brand: Allen-Bradley

• Model Number: 80190-100-01-R

• Product Type: Fiber Optic Communication Board

• System Series: PLC-5 / Rockwell Automation

• Medium: Fiber Optic (Glass or Plastic dependent on transceiver)

• Data Rate: Optimized for PLC-5 backplane speeds

• Weight: 0.06 kg

• Dimensions: 10.3 x 8.8 x 2.0 cm

• Origin: USA

• Condition: Brand New

Application Areas

The Allen-Bradley 80190-100-01-R is deployed in sectors where communication reliability is non-negotiable:

• Automotive Manufacturing: High-EMI environments near robotic welding stations.

• Energy & Utilities: Long-distance data links between distributed substations.

• Oil & Gas: Secure, isolated communication in hazardous or corrosive atmospheres.

• Heavy Industrial Machinery: Control links for large-scale milling and forging equipment.
