Product Overview

The ABB 3BHE026284R0102, model UAD215A102, is a high-performance panel controller and converter board specifically engineered for the UNITROL series of excitation systems. This unit functions as a central command interface within the power electronics assembly, bridging the gap between supervisory control logic and the physical power conversion stage. Its primary role is to manage the user interface and local control parameters for generator excitation, ensuring that voltage regulation and reactive power management are executed with high-speed precision. Designed for integration into Distributed Control Systems (DCS), the UAD215A102 provides the deterministic data processing required to maintain grid stability and synchronized generator performance.

Essential Hardware Configuration

• Model Identification: UAD215A102

• Order Designation: 3BHE026284R0102

• System Series: UNITROL Excitation (e.g., UNITROL 1000/6000)

• Communication Interface: Integrated support for industrial Ethernet and serial protocols

• Diagnostic Features: Advanced real-time fault detection and status monitoring tools

• Form Factor: Ultra-slim profile (34cm x 11.7cm x 1.5cm) for efficient cabinet integration

• Input Adaptability: Configurable voltage range to suit various industrial power infrastructures

• Net Weight: 0.22 kg

• Build Standard: High-durability PCB with thermal resilience for high-stress electrical environments

• Manufacturing Origin: Sweden

Targeted System Deployments

The UAD215A102 3BHE026284R0102 is a mission-critical component used primarily in the energy and heavy process industries. Notable applications include:

• Power Generation Facilities: Managing the excitation control panels for synchronous generators in hydro, thermal, and nuclear plants.

• Substation Regulation: Facilitating the interface for Static Var Compensators (SVC) and grid-tie converters to manage power quality.

• Marine Propulsion: Controlling the excitation of large electric drives on commercial vessels and offshore platforms.

• Industrial Power Plants: Supervising on-site generation for large-scale mining or smelting operations that require localized grid control.

• System Refurbishment: Acting as a modern replacement controller for legacy UNITROL excitation systems to extend service life and improve diagnostic visibility.
