Configured for human-machine interface processing and real-time screen data manipulation in automated control systems, the Omron NS12-TS00B-V2 (NS12-V2 Programmable Terminal) provides direct physical/electrical execution. It processes operator touch inputs and renders graphical register states across a 12.1-inch TFT display, communicating with host controllers over serial interfaces without Ethernet port reliance.

Model Number Nomenclature & Hardware Breakdown

• NS12: 12.1-inch TFT display hardware platform within the NS programmable terminal family

• TS00: Standard touch-panel display screen configuration without integrated Ethernet port

• B: Black enclosure housing bezel color

• V2: Version 2 hardware iteration supporting expanded system memory and enhanced runtime features

Electrical, Physical, & Environmental Specifications

System Memory and Firmware Flash Compatibility

The terminal relies on validated firmware flash compatibility to execute screen project files and manage host communication drivers. Internal flash memory retains system logic, screen layouts, and bit/word address mappings. Preserving firmware integrity ensures uninterrupted polling cycles, matching backplane bus communication velocity Licences when interfacing with PLC controller racks across serial links.

Package Contents

• 1 x Omron NS12-TS00B-V2 programmable terminal unit

• 1 x Set of panel mounting brackets and screws

• 1 x 24 VDC power supply connector block

• 1 x Installation instruction manual

Panel Installation & Field Wiring Guidelines

Mechanical Cutout & Enclosure Assembly

• Prepare the panel cutout according to standard enclosure dimensions, ensuring a clean and flat mounting surface.

• Insert the terminal into the cutout from the panel exterior, securing all rear mounting clamps evenly to guarantee front-bezel sealing.

Power Supply Wiring & Noise Protection

• Wire a dedicated 24 VDC power supply to the terminal block, observing correct polarity to prevent internal fuse trip.

• Connect the protective ground (FG) terminal directly to the central panel earth bar using a heavy-gauge copper strap.

Technical FAQs

• What input operating voltage is required to power the NS12-TS00B-V2 terminal?

  The unit requires a regulated 24 VDC external power supply with a maximum power consumption of 25 W.

• Does the NS12-TS00B-V2 hardware feature an onboard Ethernet port?

  No, the TS00 hardware variant is configured without an integrated RJ45 Ethernet network interface.

• What display resolution is provided by the 12.1-inch TFT screen?

  The display panel features an 800 x 600 dot (SVGA) resolution backed by a solid-state LED backlight.

• How does firmware flash compatibility affect screen project downloads?

  System firmware stored in internal flash memory must match or exceed project file runtime settings to prevent upload failures.

• What ambient operating temperature range is supported by the hardware?

  The terminal operates within an ambient temperature envelope ranging from 0 to 50 deg C.

• Is hot-swapping serial communication cables allowed while power is applied?

  No, power must be disconnected prior to attaching or removing serial leads to prevent signal line damage.

• What is the maximum weight specification for this programmable terminal?

  The unit weighs a maximum of 2.50 kg, excluding additional rear expansion interface options or cables.

• How should the panel ground terminal be routed during installation?

  Connect the FG screw terminal directly to the main cabinet ground bar via a low-impedance grounding wire.
