Configured for power conversion management in diode supply units, the ABB DSSB-01C (DSSB-01C Diode Supply Unit Control Module) provides direct physical execution of DC bus voltage monitoring and rectification stage synchronization.

Model Identification

The DSSB-01C (68300746) is a central control board engineered for the supervision of thyristor or diode-based rectification circuits. It manages DC link pre-charging and line-side synchronization within high-power drive systems.

Hardware Specifications

Parameter Specification
Model DSSB-01C 68300746
Brand ABB
Origin Sweden
Weight 1.80 kg
Shipping Dimensions 50.6 x 22.6 x 5.6 cm
Operating Temp -20 deg C to +60 deg C
Power Consumption < 10 W
Input Voltage 24 V DC (+/- 10%)

ABB Industrial Control & Drive Communication

The DSSB-01C leverages deterministic backplane bus communication velocity to maintain real-time data exchange with drive host controllers. The architecture supports I/O density scaling and firmware flash compatibility, allowing for updates to power rectification control logic. It utilizes high-speed processing to perform diagnostic analysis of line disturbances and DC bus status, ensuring that supply-side anomalies are processed within the millisecond thresholds required for effective inverter protection.

## Ordering info

  • DSSB-01C 68300746 Diode Supply Unit Control Module.

  • Mounting and interface hardware.

  • Technical manual for DSU control parameter configuration.

Field Installation Guidelines

Mounting

  • Install the module within the designated control section of the supply unit cabinet, ensuring mechanical alignment with interface connectors.

  • Secure the board using appropriate fasteners to maintain structural integrity under vibration conditions.

Wiring

  • Connect 24 V DC auxiliary power supply to the designated terminals, observing correct polarity.

  • Verify signal cabling for phase synchronization and DC bus feedback matches the specific drive system schematics to prevent control errors.

Frequently Asked Questions

  • Q: Does the DSSB-01C support hot-swapping?

    A: No. Power must be isolated from the supply unit and DC bus capacitors must be verified as fully discharged before performing any installation or maintenance.

  • Q: What is the primary function of this module?

    A: It manages rectification control, monitors incoming line phase synchronization, and coordinates the DC bus charging sequence for diode supply units.

  • Q: How does the module prevent inrush current damage?

    A: The module performs controlled charging of the DC link, regulating the current flow during the power-up sequence to prevent component stress.

  • Q: Is firmware update capability provided?

    A: Yes. The board supports firmware flashing to maintain compatibility with drive system software and rectification logic updates.

  • Q: Can this board be used in non-ABB supply units?

    A: No. It is designed specifically for integration with ABB DSU architectures; compatibility with other systems is not supported.

  • Q: How are anomalies reported to the host controller?

    A: The module reports status and error data via internal communication interfaces for logging and drive-level fault response.

  • Q: Does the board require external cooling?

    A: The module is designed for operation within its specified thermal range without auxiliary cooling, provided the cabinet environmental controls are maintained.

  • Q: What indicates that the module is powered correctly?

    A: Internal system diagnostics confirm power status and hardware health; operational data is monitored through the drive control panel interface.
