Product Overview

The ABB DSSR116, identified by part number 48990001-FK, is a specialized step-up voltage regulation module designed for critical power management within industrial automation and robotic control systems. This unit functions as a high-stability DC-to-DC converter, typically utilized to ensure consistent logic-level voltage delivery to backplanes and sensitive circuit boards. By providing a regulated 5V DC output from standard 24V DC industrial inputs, the DSSR116 maintains the operational integrity of central processing units and memory modules within a Distributed Control System (DCS). Its slot-mount architecture and ruggedized design make it an essential component for both the ABB Master system and advanced robotic controller platforms.

Hardware Parameters and Technical Specifications

The DSSR116 is engineered for continuous duty in high-demand environments, featuring integrated monitoring and protection circuitry to prevent system-wide logic failures.

• Model Number DSSR116

• Engineering Code 48990001-FK

• Primary Function Step-up / DC-to-DC Voltage Regulation

• Input Voltage 24V DC (Nominal)

• Output Voltage Regulated 5V DC

• Installation Format Slot-mounted / Rack-integrated

• Diagnostic Interface Integrated LED status indicators for power health and fault detection

• Construction Industrial-grade PCB with high-vibration resistance

• Physical Mass 1.22 kg

• Unit Dimensions 24 x 19 x 5.3 cm

• Origin Sweden

Industrial Applications and Operational Use Cases

The robust power conversion capabilities of the 48990001-FK DSSR116 are leveraged in sectors requiring 24/7 uptime and precise voltage stabilization.

• Robotic Control Systems Acts as a primary power regulator for robotic circuit boards, ensuring that the control logic receives clean, ripple-free 5V power even during the high-current draws of motor actuation.

• Advant Master DCS Racks Provides localized voltage regulation within S100 I/O racks and processor subracks to support high-speed data acquisition and logic processing.

• Manufacturing Plant Automation Deployed in control cabinets where 24V DC distribution is standard, but specialized sensors or legacy logic units require a stabilized secondary voltage.

• Power Distribution Monitoring Utilized in supervisory stations to provide redundant power paths for critical monitoring equipment, preventing data loss during primary supply fluctuations.

• System Maintenance and Retrofitting Served as a reliable replacement for aging voltage regulators in legacy ABB Master installations, ensuring continued service life of existing automation infrastructure.
