Configured for high-frequency signal propagation in rotating machinery monitoring architectures, the Bently Nevada 330130-080-01-00, also cataloged as the 330130-080-01-00 Extension Cable, provides direct physical/electrical execution.

Suffix Matrix and Configuration Breakdown

• Model Family: 330130 (3300 XL Standard Extension Cable)
• Length Designation: 080 (8.0 meters / 26.2 feet)
• Jacket Option: 01 (Armored cable construction)
• Agency Approval: 00 (Not required / standard commercial grade)

Hardware Specifications

Rotor Dynamics and Signal Transmission Integrity

Engineered to preserve signal fidelity across extended interconnect paths, the cable maintains exact eddy-current probe scaling to ensure proportional voltage output relative to shaft displacement. Gap voltage validation targets a nominal -10 VDC baseline when integrated with matching Proximitor sensors and probe tips. Additionally, robust coaxial shielding combined with stainless steel armor execution ensures cross-talk suppression and isolates the high-frequency carrier signal from electromagnetic interference inside industrial turbine housings.

Scope of Delivery Manifest

• 1 x Bently Nevada 330130-080-01-00 3300 XL Standard Extension Cable
• 1 x Threaded Connector Protective Cap Assembly
• 1 x Technical Datasheet Documentation Insert

Mechanical Routing and Installation Guidelines

• Minimum Bend Radius: Maintain a bend radius of at least 25.4 mm (1.0 inch) during physical installation for both armored and unarmored variants to prevent dielectric core distortion.
• Conductor Separation: Keep sensor cabling at least 12 inches away from high-voltage AC power lines or motor drive leads to eliminate induced noise.
• Conduit Compliance: Avoid routing sensor extension lines within the same shared conduit channel as high-voltage power feeds.

Frequently Asked Questions

• What is the physical length of this extension cable variant?

  The cable provides a total length of 8.0 meters (26.2 feet) designated by the 080 model suffix.

• What type of mechanical protection surrounds the coaxial core?

  The assembly features an integrated armored cable jacket designed to withstand harsh industrial mechanical wear.

• Does this passive cable require an external power supply connection?

  No, this component operates entirely passively without internal active circuitry or power requirements.

• What is the nominal output resistance of the internal conductors?

  The internal loop exhibits a characteristic output resistance rating of 50 Ohm.

• What is the operating temperature range for this standard extension cable?

  The component is rated to function reliably across a temperature range of -51 deg C to +177 deg C.

• How does supply voltage variation affect output performance?

  Supply sensitivity is limited to less than 2 mV change in output voltage per volt change in input voltage.

• What special hazardous area approvals are included with this option?

  The 00 suffix indicates that specific hazardous location agency approvals are not required for this build.

• What is the total verified shipping weight including packaging?

  The gross package weight including standard shipping materials is 0.84 kg.
