Configured for single-axis drive control execution in Allen-Bradley ControlLogix automation platforms, the Allen-Bradley 1756-DMD30 (1756-DMD30 Drive Control Module) provides direct motion control processing through fiber optic communication and 24 VDC interface circuits.

Model Configuration Details

The 1756-DMD30 is a ControlLogix drive module designed for one-axis drive control applications. The module provides drive interface functionality with LED status indicators, fiber optic communication capability, and a 24 VDC power interface.

The module requires 1.35 A at 5.1 VDC from the ControlLogix backplane and provides a dedicated hardware interface for motion-related control operations within compatible ControlLogix chassis configurations.

Hardware Specifications

ControlLogix Motion Communication Characteristics

The 1756-DMD30 uses Allen-Bradley industrial control architecture for drive communication and single-axis control applications. The module supports firmware flash compatibility considerations when integrated into existing ControlLogix systems.

Fiber optic communication provides an interface path for drive-related data exchange, while the ControlLogix backplane manages module communication and controller data processing. Proper chassis configuration and controller firmware matching are required during system integration.

Ordering Information

The standard shipment configuration includes:

• 1 x Allen-Bradley 1756-DMD30 ControlLogix Drive Control Module
• 1 x Factory product identification label
• 1 x Original hardware assembly

Additional components such as fiber optic cables, ControlLogix chassis hardware, power supplies, and drive interface accessories depend on the installed motion control system requirements.

Field Installation Guidelines

Module Installation

• Install the module in a compatible ControlLogix chassis slot according to the system configuration.
• Verify backplane power availability before module installation.
• Confirm controller and module firmware compatibility before commissioning.

Fiber Optic Connection

• Inspect fiber optic connectors for contamination before connection.
• Avoid excessive bending or mechanical stress on fiber optic cables.
• Maintain proper cable routing away from sources of physical damage.

Thermal Management

• Install the module within the specified operating temperature range.
• Maintain sufficient enclosure ventilation according to system design.
• Consider total chassis thermal loading during system expansion.

Frequently Asked Questions

• What is the main function of the 1756-DMD30?

  The 1756-DMD30 is a ControlLogix drive module designed for single-axis drive control applications using compatible motion control architectures.

• How many axes can this module control?

  The module is specified for one-axis drive control operation and provides dedicated hardware support for a single motion axis.

• What power supply requirement does the module have?

  The module requires 1.35 A at 5.1 VDC from the ControlLogix chassis backplane power system.

• Does the module use fiber optic communication?

  Yes. The 1756-DMD30 includes fiber optic communication capability for drive interface connections.

• What is the peak power dissipation value?

  The specified peak power dissipation is 6.96 Watts, with thermal dissipation listed as 23.7 BTU per hour.

• Can this module operate outside the listed temperature range?

  Operation should remain within the specified 32 to 140 deg F range to maintain normal hardware performance.

• Does the module provide LED diagnostics?

  Yes. The module includes LED indicators for monitoring operational status and module conditions.

• Is firmware compatibility required for installation?

  Yes. The module firmware must be compatible with the ControlLogix controller and chassis configuration.
