Product Overview

The Yokogawa ADV151-P50 S2 is a high-density digital input module specifically engineered for the FIO (Field network I/O) architecture within the CENTUM VP Distributed Control System (DCS). This module serves as a high-reliability interface for gathering discrete status data from field-level devices such as limit switches, pushbuttons, and relay contacts. Featuring 32 isolated channels, the ADV151-P50 S2 provides the high I/O density necessary for complex automation environments, converting external 24V DC binary signals into logic for the Field Control Station. Its robust construction ensures deterministic reporting and system stability for mission-critical process monitoring.

Technical Characteristics

The ADV151-P50 S2 is designed with a focus on wiring flexibility and industrial durability:

High-Density Discrete Monitoring With 32 channels integrated into a single slim module, this unit maximizes cabinet space efficiency. It allows for the centralized acquisition of numerous field status points, which is essential for large-scale process plants where rack space is at a premium.

Flexible Input Configuration The module is designed for 24V DC logic and supports versatile field wiring. It can be configured to accommodate various signal types, ensuring compatibility with different sensor and switch technologies found across diverse industrial sectors.

Secure Connectivity Options The hardware utilizes a pressure clamp terminal system for direct field wiring, ensuring vibration-resistant and gas-tight connections. For streamlined installation, the module is also compatible with dedicated Yokogawa signal cables, such as the AKB331 and standard MIL connector assemblies, allowing for rapid deployment and simplified maintenance.

Industrial Resilience and Precision Built for continuous 24/7 operation, the ADV151-P50 S2 maintains signal integrity in harsh electrical environments. The isolation between the field side and the system side prevents external surges or noise from impacting the internal DCS backplane, guaranteeing the accuracy of status reporting for safety interlocks and sequence control.

Technical Specifications

• Brand: Yokogawa

• Model Number: ADV151-P50 S2

• Product Type: Digital Input Module

• Channels: 32 (Isolated)

• Rated Input Voltage: 24 V DC

• System Compatibility: CENTUM VP / CS 3000 (FIO System)

• Input Format: Sink or Source capability

• Connection Method: Pressure Clamp Terminal / MIL Connector

• Weight: 0.24 kg

• Dimensions: 3.2 x 10.6 x 13 cm

• Origin: Japan

Application Areas

The Yokogawa ADV151-P50 S2 is a staple component in high-reliability industrial automation, including:

• Petrochemical Refining: Monitoring of valve limit switches and safety shutdown triggers.

• Power Generation: Tracking auxiliary contact statuses and plant-wide alarm signals.

• Water Treatment: Integrating discrete float switches and pump run/stop feedback.

• Manufacturing: Collecting signal data from manual control stations and equipment interlocks.
