Product Overview

The Yokogawa ADV141-P10 S1 is a high-performance digital input module engineered for the CENTUM VP Distributed Control System (DCS). Functioning as a primary interface between field equipment and the control station, this module is designed to capture 16 channels of discrete signals from devices such as pressure switches, limit switches, and motor relay contacts. The "P10" specification indicates a pressure-clamp terminal connection interface, providing a secure and vibration-resistant wiring solution for industrial cabinets.

By utilizing advanced microprocessor-driven logic, the ADV141-P10 S1 ensures rapid signal detection and precise data processing. It is built on Yokogawa's FIO (Field Interface Orbus) architecture, allowing for high-density I/O configurations while maintaining robust electrical isolation. This ensures that the system logic remains protected from field-side voltage spikes and noise, making it an essential component for critical process control in energy, chemical, and manufacturing sectors.

Technical Specifications

• Manufacturer: Yokogawa

• Model Number: ADV141-P10 S1

• Number of Channels: 16-channel, isolated

• Input Signal Type: 24 V DC (Dry or Wet Contact)

• Input Current: Approximately 4.1 mA (at 24 V DC)

• Data Refresh Cycle: 10 ms

• Isolation Voltage: 1500 V AC between input signals and system logic

• Interface Style: Pressure-clamp terminal (P10 variant)

• Current Consumption: Max. 250 mA (5 V DC)

• Weight: 0.28 kg

• Dimensions: 32.8 mm x 106.3 mm x 130 mm

• Operating Temperature: -20°C to +70°C

• Origin: Japan

Core Features and Performance

• Reliable Signal Acquisition: Supports 16 isolated channels with high-speed sampling, ensuring real-time status updates for complex industrial sequences.

• Robust Opto-Isolation: Features 1500V AC galvanic isolation to safeguard the internal system bus from field-side electrical interference and ground loops.

• Industrial Durability: Constructed with high-grade components to operate continuously in extreme climates and harsh environments, significantly reducing maintenance overhead.

• Redundancy Support: Compatible with dual-redundant configurations in CENTUM VP nodes, enabling seamless failover and preventing data loss during hardware faults.

• System Integration: Fully compliant with IEC 61131-3 standards for easy programming and configuration within the Yokogawa engineering environment.

• Hot-Swap Capability: Designed to allow module replacement during active system operation, facilitating efficient maintenance without process interruption.
