UCD224 A101 3BHE023681R0101 ABB UNITROL Input Filter Module
UCD224 A101 3BHE023681R0101 ABB UNITROL Input Filter Module
UCD224 A101 3BHE023681R0101 ABB UNITROL Input Filter Module
ABB

UCD224 A101 3BHE023681R0101 ABB UNITROL Input Filter Module

SKU: 3BHE023681R0101
Categories : ABB
In Stock
  • Dimensions: 33cm x 3cm x 16.7cm
  • Country of origin: Sweden
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Product Overview

The 3BHE023681R0101 UCD224 A101 is a high-reliability Input Filter Module developed for the ABB UNITROL excitation system series. This specialized hardware component is engineered to safeguard sensitive control electronics by suppressing electromagnetic interference (EMI) and filtering high-frequency noise from input power and signal lines. By ensuring a clean electrical supply to the Automatic Voltage Regulator (AVR), the UCD224 A101 maintains the integrity of the excitation logic, preventing signal distortion that could lead to generator instability. Its robust design is specifically tailored to meet the rigorous demands of power generation environments where electrical noise from high-power switching is prevalent.

Hardware Infrastructure and Protective Specifications

The UCD224 A101 is built with industrial-grade materials to provide superior attenuation and long-term durability in high-voltage control cabinets.

  • Filter Type: High-performance passive EMI/RFI suppression.

  • Ingress Protection: IP67 rated against moisture, dust, and particulate contamination.

  • Electrical Isolation: Class 2 insulation rating for enhanced personnel and equipment safety.

  • Interface Design: Features ruggedized M12 x 2 connection points for secure, vibration-resistant seating.

  • Operating Envelope: Rated for continuous service in ambient temperatures from -20°C to +85°C.

  • Physical Profile: 33cm x 3cm x 16.7cm.

  • Net Mass: 0.5 kg.

  • Conductor Composition: High-conductivity copper alloy internal paths for minimal thermal loss.

Strategic Industrial Implementations

As a vital protective node in the UNITROL ecosystem, the 3BHE023681R0101 is predominantly found in power plant control rooms and substations. In hydroelectric and thermal power facilities, it serves as the primary defense for the excitation system's input stages, filtering out the volatile transients generated during large-scale load shedding or grid synchronization. It is equally indispensable in heavy manufacturing sites—such as smelting plants and large-scale paper mills—where the stability of synchronous motors is dependent on noise-free control signals. The module’s quick-install design allows maintenance teams to integrate or replace the filter within a DCS rack with minimal downtime, ensuring that automated systems remain productive and shielded from the harsh electrical realities of modern industrial power distribution.
