Product Overview

The Siemens 6ES7193-6PA00-0AA0 is a fundamental structural component of the SIMATIC ET 200SP distributed I/O system. Functioning as the mandatory station terminator, this server module is installed at the far right end of the ET 200SP configuration. Beyond merely closing the backplane bus, it facilitates essential internal communication and potential group bridging, ensuring that data and power circuits are correctly terminated for stable operation. This module is required for every ET 200SP station to complete the local bus circuit, making it an indispensable part of the system's mechanical and electrical architecture.

Technical Performance and Mechanical Data

This module is built to endure extreme environmental variables while maintaining a small footprint within the control cabinet. Note: While specific dimensions for the server module are compact, the following parameters define its operational envelope:

• System Role: Final station termination and backplane bus closure.

• Wiring Technology: Integrated push-in terminals for tool-free, vibration-resistant connectivity.

• Altitude Rating: Operational capability at elevations up to 5,000 meters above sea level.

• Thermal Range: Reliable performance from -30 °C to +60 °C (horizontal mounting).

• Net Weight: 0.19 kg (Packaged/Gross weight).

• Module Dimensions: 0.7 cm x 11.7 cm x 3.6 cm (referencing full station depth and vertical profile).

• Data Integrity: Maintains consistent potential group continuation across the backplane.

Industrial Environments and Functional Scenarios

The 6ES7193-6PA00-0AA0 is a universal requirement for any ET 200SP deployment, particularly in sectors that demand high availability and ruggedness:

• Cold Storage and Outdoor Cabinets: The extended temperature range (down to -30 °C) allows for deployment in refrigerated logistics or remote environmental monitoring stations.

• High-Altitude Infrastructure: Its 5,000m altitude certification makes it the standard choice for wind turbines located in mountainous regions or high-altitude mining operations.

• High-Vibration Machinery: The push-in terminal design ensures that electrical contacts remain secure in manufacturing plants featuring heavy stamping or rotating equipment.

• Scalable Distributed I/O: Whether a station consists of three modules or thirty, this server module provides the necessary bus termination to allow the head station (Interface Module) to recognize the full hardware configuration.
