Product Overview

The Schneider Electric ATV71HD75N4Z is a high-performance 75 kW (100 hp) frequency inverter designed specifically for heavy-duty industrial motors. Part of the specialized Altivar 71 family, this drive excels in managing complex machinery that requires high torque and precise speed regulation. Operating on a 380V to 480V three-phase supply, the unit provides exceptional motor control for both synchronous and asynchronous systems. This specific "Z" variant is optimized for cabinet integration, typically arriving without a graphic display terminal to allow for customized interface setups via external control systems or remote HMI panels.

Mechanical Specifications and Technical Profiles

The ATV71HD75N4Z is engineered to sustain high output levels while protecting internal circuitry from electrical surges.

• Power Capacity: 75 kW / 100 hp (109.9 kVA apparent power)

• Frequency Output Range: 0.1 Hz to 500 Hz

• Physical Mass: 32 kg

• Unit Dimensions: 27.9 x 21.6 x 6.3 cm

• Short-Circuit Rating: Handles prospective currents up to 22 kA

• Switching Frequency: 2.5 kHz nominal (optimized for heavy-duty thermal management)

• Electromagnetic Compatibility: Integrated EMC filter included as standard

• Construction: Designed for durability and long-cycle sustainability under the "Use Better, Use Longer" initiative

Industrial Utility and Deployment Scenarios

This Variable Speed Drive is a cornerstone for sectors where mechanical precision directly impacts operational throughput and energy efficiency.

Heavy Lifting and Material Handling: Managing high-inertia loads in cranes and hoists where constant torque and safe braking are mandatory for site safety.

Fluid Dynamics and Processing: Controlling high-capacity pumps and compressors in chemical or water treatment facilities, utilizing variable frequency to significantly lower energy consumption.

Bulk Material Mining: Driving conveyor systems and crushers that face frequent load fluctuations and require robust short-circuit protection.

Metal and Woodworking Machinery: Providing the high-speed accuracy required for extruders, mixers, and industrial grinders where motor performance determines product quality.

Large-Scale HVAC and Infrastructure: Managing massive fan arrays and ventilation systems in industrial complexes to maintain environmental standards while reducing the carbon footprint.
