Configured for discrete signal switching and auxiliary power isolation in control panel automation enclosures, the Omron R7M-A40030-BS1 (MY4NJAC110120 General Purpose Relay) provides direct physical/electrical execution.

Model Identification & Code Designation

  • R7M-A40030-BS1: Commercial catalog order reference designation
  • MY: Standard general-purpose plug-in power relay platform
  • 4: 4PDT (4 Form C) contact pole layout
  • N: Built-in LED operation indicator mechanism
  • J: Plug-in terminal structure for mounting socket interfaces
  • AC110/120: Nominal coil excitation voltage rating (110 to 120 VAC)

Electrical & Physical Specifications

Parameter Specification
Model R7M-A40030-BS1 (Alias: MY4NJAC110120)
Brand Omron
Origin Japan
Weight 0.035 kg (1.23 oz)
Base Unit Dimensions 21.5 mm x 28 mm x 36 mm
Shipping Dimensions 100 mm x 60 mm x 50 mm (Shipping weight: 0.15 kg)
Operating Temp -55 deg C to 70 deg C
Power Consumption 1.1 VA (Coil power draw at 60 Hz)
Coil Voltage 110 VAC to 120 VAC
Contact Rating 5 A at 250 VAC / 125 VDC
Contact Configuration 4PDT (4 Form C, 4PDT-NO/NC)
Contact Material Silver (Ag)
Mounting Style Plug-in socket mounting

Control Backplane Integration & Network Determinism

The relay provides reliable physical isolation between low-voltage digital output cards and high-power load circuits across PLC control cabinets. Rapid contact switching times preserve system response speeds across Profinet / EtherNet/IP deterministic networks during high-density I/O density scaling routines. Upstream controller modules utilize stable backplane bus communication velocity Licences and uniform firmware flash compatibility to process field feedback signals without loop delays.

Package Delivery Contents

  • 1 x R7M-A40030-BS1 Power Relay Module
  • 1 x Protective Dust Cover Frame
  • 1 x Technical Specification Sheet

Socket Integration & Panel Wiring Protocol

Physical Socket Installation

  • Insert the relay pin terminal base vertically into a compatible DIN-rail socket until the plastic retaining clips lock firmly.
  • Ensure at least 10 mm lateral spacing between adjacent relay sockets to ensure adequate heat dissipation under full load continuous duty.

Terminal Wiring Directives

  • Connect 110/120 VAC control line wires directly to socket coil terminals A1 and A2.
  • Wire field load circuits across the numbered 4PDT contact screw terminals, ensuring continuous conductor currents remain under 5 A.

Frequently Asked Questions

  • What is the continuous current capacity per pole on this relay?

    Each silver contact pole handles a maximum continuous current rating of 5 A at 250 VAC or 125 VDC.

  • What coil excitation voltage range is required for operation?

    The non-latching electromagnetic coil operates within an AC supply voltage range of 110 VAC to 120 VAC.

  • What contact arrangement is available inside the sealed housing?

    The unit features a 4PDT (4 Form C) contact setup providing four independent NO and NC switching channels.

  • How is the relay physically attached inside a control cabinet?

    The housing features plug-in spade terminals designed for snap-in mounting into standard matching DIN-rail sockets.

  • Does the relay include an integral visual status indicator?

    Yes, the MY4NJ variant incorporates an integrated LED indicator that illuminates when the coil is energized.

  • What is the nominal power consumption of the AC drive coil?

    The electromagnetic drive coil consumes approximately 1.1 VA during steady-state 110/120 VAC excitation.

  • What contact material is utilized for reliable switching performance?

    The switching contacts are constructed from solid silver (Ag) alloy to ensure low contact resistance.

  • Can this relay be mounted directly to a printed circuit board?

    No, this specific plug-in terminal model requires a compatible relay socket for panel wire termination.
