Product Overview

The ABB PU516, identified by order number 3BSE013064R1, is a high-level engineering interface module designed for the System 800xA Distributed Control System (DCS) environment. This board serves as a vital bridge for system configuration, providing the high-speed data throughput necessary for engineering workstation communication and controller-level interfacing. Engineered to handle complex automation architectures, the PU516 facilitates the deployment of control logic and the management of fieldbus topologies. It is a critical hardware component for maintaining the integrity of industrial networks, ensuring that engineering commands and diagnostic data are transmitted with absolute precision across the system backbone.

System Specifications & Hardware Details

• Module Identification: PU516 Engineering Board

• Product ID: 3BSE013064R1

• Primary Series: System 800xA / AC 800M

• Networking Compatibility: Extensive support for industrial protocols including EtherCAT, DeviceNet, and CANopen

• Physical Mass: 0.34kg

• Form Factor: 32.5cm x 12.6cm x 1.7cm

• Functional Integration: Supports Ethernet router services for centralized system telemetry

• Origin of Manufacture: Sweden

• Environmental Build: Industrial-grade PCB designed for continuous operation in high-density controller racks
