Configured for high-density discrete signal execution and real-time network communications in CP2E Series networks, the Omron CP2E-N60DR-D (CP2E-N60DR-D Programmable Controller) provides direct physical/electrical execution. It handles 36 discrete 24 VDC input channels and 24 electromechanical relay outputs to drive field contactors, solenoids, and status indicators. Internal logic processing coordinates direct discrete signaling with embedded dual Ethernet connectivity.

Technical Identifier Matrix

Hardware Specifications

I/O Density Scaling and Backplane Bus Velocity

The Omron CP2E-N60DR-D maximizes panel footprint efficiency by incorporating 60 discrete channels on a single base chassis. System throughput is maintained across the internal CPU architecture by optimizing backplane bus velocity during local update loops. High I/O density scaling allows connection of up to 3 CP1W expansion modules to extend channel density without degrading program scan time or Ethernet message priority.

Package Contents & Ordering Information

• 1x Omron CP2E-N60DR-D CPU Unit

• 1x Removable Terminal Cover Assembly

• 1x Hardware Installation Sheet

Field Installation Guidelines

• Mounting Setup: Mount horizontally on a 35 mm DIN rail or attach via direct M4 screw panel connections. Maintain 50 mm clearance above and below for ventilation.

• Supply Wiring: Supply main power using 24 VDC (20.4 to 26.4 VDC range) connected to dedicated power terminals.

• Relay Output Suppression: Install external surge suppressors across AC inductive loads and RC snubber circuits or flywheel diodes across DC loads to prevent contact pitting.

• Grounding: Connect a dedicated low-impedance ground wire (minimum 2.0 mm sq) to the functional earth terminal.

• Shielding: Terminate communications and high-speed signal cable shields using 360-deg braid shield grounding techniques.

Frequently Asked Questions

• Q: What is the main operating voltage requirement for the CP2E-N60DR-D CPU?

  A: The module operates on a nominal supply voltage of 24 VDC, with an acceptable operating range of 20.4 to 26.4 VDC.

• Q: What type of outputs are present on the CP2E-N60DR-D?

  A: The unit features 24 electromechanical relay outputs rated for 2 A per point at 250 VAC or 30 VDC.

• Q: What is the 5 VDC internal backplane current draw for this model?

  A: The internal current consumption from the 5 VDC rail is 0.41 A, while the 24 VDC consumption is 0.13 A.

• Q: How many built-in Ethernet network ports are provided on the base unit?

  A: The controller incorporates 2 built-in RJ45 Ethernet ports with switching capability for daisy-chain topology.

• Q: How many CP1W expansion modules can be added to the base CPU?

  A: Up to 3 CP1W discrete or analog expansion modules can be connected to scale local channel capacity.

• Q: What is the allowable ambient operating temperature range?

  A: The housing and internal components are specified for operational ambient temperatures from 0 to 55 deg C.

• Q: How should external inductive loads on relay contacts be protected?

  A: Flywheel diodes must be wired across DC loads, and RC snubbers must be wired across AC loads to absorb counter-EMF.

• Q: What shielding method is recommended for network cabling connections?

  A: Use STP cable with proper 360-deg braid shielding terminated directly to ground to reject high-frequency noise.
