Product Overview

The Honeywell MLI-DR32H/D1 is a multifunctional control component designed for the MasterLogic programmable controller series. This unit operates as a high-density hybrid module, integrating digital signal inputs with high-capacity relay outputs to provide a comprehensive interface for field devices. Built for the rigors of Distributed Control Systems (DCS), it features a dual-voltage power architecture that supports both 12V and 24V DC standards. By combining logic processing with mechanical switching, the MLI-DR32H/D1 serves as a versatile node for controlling heavy-duty industrial hardware while maintaining high-speed instruction execution for complex automation sequences.

Essential Hardware Metrics and Technical Data

• Model Identification: MLI-DR32H/D1

• Input Configuration: 16-Point Digital (12V/24V DC)

• Output Configuration: 16-Point Relay (Dry Contact)

• Switching Capacity: 2A at 24V DC / 2A at 220V AC (Resistive)

• Logic Processing Speed: 83ns per basic instruction step

• Wiring Architecture: 4 points per Common (COM) group

• Mechanical Endurance: > 20,000,000 cycles

• Scalability: Supports expansion up to 384 I/O points

• Isolation Type: Electromechanical relay insulation

• Dimensions & Weight: 7x14x14.5cm | 0.4kg

Industrial Implementation and Control Scenarios

The MLI-DR32H/D1 is specifically engineered for environments requiring robust electrical isolation and the ability to drive higher current loads directly from the PLC rack.

• Actuator & Solenoid Management: Directly driving 220V AC solenoid valves or motor starters without the need for interposing relays, reducing cabinet space and wiring complexity.

• Safety & Status Indication: Managing large arrays of industrial beacons, sirens, and status indicators across a manufacturing floor.

• Complex Digital Logic: Utilizing the 83ns processing speed to handle high-frequency pulse detection and rapid-fire logic transitions in packaging or material handling systems.

• Global Power Adaptation: Deploying across international facilities due to its flexible 12/24V DC input compatibility, allowing for standardized spare parts inventory.
