Product Overview

The Bachmann LX700/DD256/CF512MB is a high-performance central processing unit engineered to serve as the computational core of the M1 automation platform. Designed for industrial applications requiring deterministic logic execution and high-speed data handling, this module coordinates complex control sequences across extensive I/O networks. With a 700 MHz processor at its center, the unit provides the necessary throughput for multi-axis motion control and sophisticated process regulation, ensuring that mission-critical tasks are performed with microsecond precision.

This control module is equipped with 256 MB of high-speed DDR RAM for volatile memory tasks and a 512 MB CompactFlash card for non-volatile storage. This combination allows for the efficient execution of large-scale user programs while providing ample capacity for localized data archiving, system logs, and the VxWorks-based operating system. Its architectural design focuses on providing a stable, high-speed environment for industrial algorithms in heavy-duty automation sectors.

Thermal Efficiency and Data Persistence

A defining characteristic of the LX700 series is its optimized power-to-performance ratio. By utilizing low-voltage internal operation (1.2V), the module achieves high clock speeds while maintaining a minimal thermal footprint. This low heat dissipation is vital for high-density control cabinets, as it reduces the thermal stress on adjacent modules and eliminates the need for active cooling in many configurations.

To ensure maximum process safety, the LX700/DD256/CF512MB incorporates integrated retentive memory. This technology safeguards critical process variables and machine states during unexpected power interruptions, allowing for a controlled and predictable system restart. The module also features a front-accessible CF card slot, which simplifies the process of firmware management and hardware replacement by allowing storage media to be swapped without removing the module from the backplane.

Technical Specifications

• Manufacturer: Bachmann Electronic

• Model Number: LX700/DD256/CF512MB

• Processor Frequency: 700 MHz

• Volatile Memory: 256 MB DDR RAM

• Non-Volatile Storage: 512 MB CompactFlash (CF)

• Internal Operating Voltage: 1.2V

• Software Compatibility: Bachmann M1 Controller System / VxWorks

• Module Form Factor: Single-slot width (5.3 cm)

• Weight: 0.22 kg

• Dimention: 28.8 cm x 18.6 cm x 8 cm

• Data Retention: Integrated retentive storage for power-fail protection

Strategic Industrial Applications

• Renewable Energy: Managing pitch, yaw, and grid synchronization logic for large-scale wind turbines.

• Marine Systems: Powering propulsion control, engine monitoring, and integrated bridge systems for maritime vessels.

• Precision Manufacturing: Coordinating synchronized multi-axis movements in high-speed robotics and specialized production lines.

• Process Infrastructure: Handling high-volume telemetry and data acquisition for predictive maintenance in utility plants.
