Configured for fieldbus protocol conversion and network bridging in distributed control architectures, the ABB LD800HSE 3BDH000320R02, also cataloged as the LD800HSE Linking Device, provides direct physical and electrical execution for routing data between Ethernet and fieldbus communication tiers.

Part Number Breakdown & Configuration Matrix

Hardware Specifications

Backplane Bus & Network Communication Parameters

The hardware utilizes backplane bus communication velocity licences to maintain deterministic packet transfers across network segments. I/O density scaling capabilities allow system expansion without violating bus update intervals or protocol timing constraints. Firmware flash compatibility ensures that communication stacks remain synchronized across distributed node architectures during active process operations.

Package Contents & Ordering Info

• 1 x ABB LD800HSE Linking Device (Part Number: 3BDH000320R02)
• 1 x RJ45 Network Patch Cable Assembly
• 1 x Technical Compliance Documentation Leaflet

Field Installation Guidelines

• Mount the linking device securely onto a standard industrial DIN-rail, ensuring proper mechanical latching.
• Connect the Ethernet interface using a shielded Cat5e or higher cable to the 10BASE-T/100BASE-TX RJ45 port.
• Terminate the 4-channel fieldbus wiring to the designated connection terminals, maintaining correct polarity.
• Verify that ground continuity is established between the device chassis and the cabinet grounding bus to minimize noise.

Frequently Asked Questions

• Q: What is the primary operational function of this linking device within the control system?
• A: It bridges high-speed Ethernet networks with lower-speed fieldbus communication channels.
• Q: How many communication channels does the unit support?
• A: The hardware supports 4 independent fieldbus channels alongside standard Ethernet connectivity.
• Q: What data transfer rates are supported on the Ethernet port?
• A: The RJ45 port supports autosensing data rates of 10 Mbit/s and 100 Mbit/s.
• Q: What is the specified operating temperature range for the hardware?
• A: The device operates reliably within an ambient temperature range of 0 deg C to +55 deg C.
• Q: Does this device require an external power supply connection?
• A: Yes, it requires a stable DC power input to sustain internal processing and communication circuits.
• Q: What precautions should be taken during fieldbus wiring installation?
• A: Ensure proper shielding and termination resistors are utilized to prevent signal reflections and data corruption.
• Q: Can the device firmware be updated in the field?
• A: Yes, firmware flash compatibility allows updates to maintain protocol synchronization with controller nodes.
• Q: What maintenance procedures are recommended for this hardware?
• A: Regularly inspect terminal torque settings and verify that ventilation clearances around the housing remain unobstructed.
