Product Overview

The GE IC695PNS001CA-ABAH is a sophisticated network interface module designed to integrate remote I/O racks into a high-speed PROFINET ecosystem. Engineered specifically for the PACSystems RX3i architecture, this scanner serves as a bridge, allowing a central PROFINET Controller to manage remote Series 90-30 or RX3i I/O modules over an Ethernet-based LAN. It functions by autonomously scanning the local rack and synchronizing input/output data with the master controller at user-defined production rates. This module is essential for distributed control architectures where real-time responsiveness and high-density data throughput are required across geographically dispersed equipment racks.

Core Network Capabilities and Hardware Architecture

• Multi-Port Switching: Features four integrated Ethernet ports supporting 10/100/1000 Mbps speeds, allowing for flexible copper and fiber optic connectivity.

• Topological Versatility: Fully compatible with star, daisy-chain, and ring topologies, including support for Media Redundancy Protocol (MRP) to ensure system uptime during cable failure.




• Tool-Less Replacement: Includes an SD card slot that stores the I/O Device Name, allowing for rapid module swaps without the need for a specialized configuration PC.




• Connectivity Standards: Equipped with a dedicated RJ-45 front-panel port for local firmware management and maintenance.

• Fail-Safe Logic: Programmable I/O default states ensure that field devices transition to a safe condition if network communication is interrupted.

Strategic Industrial Deployment Scenarios

The IC695PNS001CA-ABAH is a cornerstone for modernizing industrial networks and implementing distributed intelligence. Common applications include:

Distributed Manufacturing Lines: Linking multiple assembly stations to a single RX3i controller via PROFINET, reducing wiring costs while maintaining millisecond-level synchronization.

Water and Wastewater Treatment: Managing remote pump stations and sensor clusters over long distances using fiber optic extensions supported by the module's high-speed ports.

Redundant Infrastructure: Utilizing Media Redundancy Protocol (MRP) in critical processing plants to ensure that a single broken Ethernet cable does not lead to a total system shutdown.

Energy Management: Integrating remote power monitoring I/O with central DCS platforms for real-time load balancing and historical data acquisition.

Legacy Migration: Bridging existing Series 90-30 I/O racks into newer RX3i PROFINET control networks, extending the lifecycle of established hardware investments.
