Product Overview

The GE Fanuc IC693MDL231 is a high-voltage discrete input module for Series 90-30 PLC systems, built to monitor 240 VAC field signals with channel-to-channel isolation. It provides 8 isolated input points for bringing AC status signals into the controller, supporting common industrial devices powered from external AC sources.

Front-panel LEDs provide at-a-glance verification of each input state to support commissioning and troubleshooting. The module mounts in standard Series 90-30 baseplates, allowing straightforward expansion or replacement in installed control systems.

Hardware Parameters

• Model / Order Number: IC693MDL231

• Product Family: Series 90-30

• Product Type: PLC Isolated AC Input Module

• Input Points: 8 isolated inputs

• Rated Input Voltage: 240 VAC class

• Input Wiring: Each point uses an external power source and dedicated input connection

• Indication: 8 channel status LEDs

• Identification: High-voltage marking on front insert for safety recognition

• Installation: Fits Series 90-30 5-slot and 10-slot baseplates

• Condition: Brand New, In Stock, Active

• Origin: USA

• Weight: 0.28 kg

• Dimensions: 3.5 × 13 × 13.5 cm

• HS Code: 8537101190

• MOQ: 1

Industrial Applications

• Monitoring limit switches, pushbuttons, and auxiliary contacts on AC control circuits

• Reading AC proximity or electronic switch outputs in legacy machine panels

• Interface to 240 VAC status signals in material handling and process equipment

• Maintenance replacement for Series 90-30 high-voltage input modules in existing PLC racks
