Product Overview

The HIMA F3DIO20/802 is a high-integrity remote I/O unit engineered for distributed safety-related automation within the HIMatrix ecosystem. This module acts as a bridge between field instrumentation and the central safety controller, offering 20 digital input channels and 8 digital output channels, all featuring galvanic isolation to protect against electrical interference. Designed for mission-critical Safety Instrumented Systems (SIS), it ensures that logic signals are processed with the deterministic speed and accuracy required for high-risk industrial environments.

By utilizing the "safeethernet" protocol, the F3DIO20/802 allows for decentralized system architectures, reducing field wiring costs while maintaining a SIL 3 safety integrity level. Its compact, rugged design makes it suitable for integration into localized control cabinets across various sectors, including energy, chemical processing, and discrete manufacturing.

Technical Characteristics

• Channel Configuration: 20 Galvanically isolated digital inputs and 8 isolated digital outputs

• Safety Ratings: Certified for SIL 3 (IEC 61508) and PL e / Category 4 (EN ISO 13849-1)

• Power Supply: Standard 24 VDC industrial supply voltage

• Input Specifications: TTL-compatible signal levels for flexible field device interfacing

• Isolation: Individual channel isolation to maximize system reliability and fault tolerance

• Software Support: Fully programmable and configurable via the ELOP II Factory engineering tool

• Operating Temperature: Stable performance from 0°C to +60°C

• Mechanical Dimensions: 20.5 x 7.5 x 11.0 cm

• Weight: 0.86 kg

• Country of Origin: Germany

Safety Performance and Field Integration

The F3DIO20/802 is built on a fault-tolerant architecture that emphasizes fail-safe operation. In the event of a communication disruption or hardware anomaly, the module initiates a safety shutdown of outputs to ensure the process reaches a safe state. The integration of 20 inputs allows for comprehensive monitoring of complex safety loops, such as multi-point emergency stops, light curtains, and pressure transmitters.

Maintenance and commissioning are streamlined through the ELOP II Factory environment, which provides clear diagnostic visibility. The module's isolated I/O channels prevent the propagation of ground loops and voltage spikes, which is essential for high availability in electrically noisy industrial settings. Whether used for localized machine safety or as part of a plant-wide Distributed Control System (DCS), the F3DIO20/802 delivers the uncompromising safety performance that HIMA is globally recognized for.
