H8PS-8BP Omron H8PS Cam Positioner

SKU: H8PS-8BP
Categories : All Products
In Stock
  • Dimensions: 96 mm x 96 mm x 67.5 mm
  • Country of origin: Japan
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Configured for shaft angle tracking and rotational setpoint execution in automated packaging and assembly machinery, the Omron H8PS-8BP (H8PS Cam Positioner) provides direct physical/electrical execution. It decodes position pulses from an absolute encoder input and toggles 8 discrete PNP open-collector transistor outputs across configured angular thresholds.

Technical Model Code & System Structure

  • H8PS: Standard 1/4 DIN (96 x 96 mm) electronic cam positioner platform
  • 8: 8 discrete transistor output channels for sequential timing control
  • B: Integrated backlit LCD interface screen for real-time angle monitoring
  • P: PNP open-collector output transistor switching configuration

Hardware Specifications

Parameter Specification
Model H8PS-8BP
Brand Omron
Origin Japan
Weight Approx. 300 g
Shipping Dimensions 96 mm x 96 mm x 67.5 mm
Operating Temp -10 to 55 deg C
Power Consumption Approx. 15 VA max.
Rated Input Voltage 24 VAC (20.4 to 26.4 VAC allowable)
Display System Backlit LCD
Input Configuration Absolute encoder input
Output Stage 8 x PNP transistor outputs
Mounting Type On-panel flush mounting

Execution Logic & I/O Density Scaling

The internal microcontroller processes encoder feedback vectors to synchronize output states with active mechanical shaft positions. Managing high-speed angle decoding while supporting flexible I/O density scaling allows expansion across complex multi-axis control architectures. Maintaining system firmware flash compatibility prevents timing drift, matching backplane bus communication velocity Licences when updating controller parameters.

Package Scope

  • 1 x Omron H8PS-8BP cam positioner
  • 1 x Panel flush mounting bracket kit
  • 1 x Waterproof panel mounting rubber gasket
  • 1 x Operating instruction manual

Field Installation & Wiring Guidelines

Panel Cutout & Mechanical Fastening

  • Prepare a standard 92 x 92 mm square cutout in the enclosure door, clearing all metal burs from the edges.
  • Seat the rubber sealing gasket against the front bezel flange and push the housing into the cutout, tightening the panel adapters until snug.

Signal Termination & Direction Setup

  • Set the DIP switches on the unit to configure the encoder rotation direction for clockwise (CW) or counter-clockwise (CCW) operation before applying power.
  • Wire the absolute encoder leads directly to the dedicated input terminals using shielded twisted-pair cabling separated from AC power lines.

Frequently Asked Questions

  • What operational AC supply voltage range is required for the H8PS-8BP unit?

    The unit runs on a nominal 24 VAC control supply with an allowable operational range between 20.4 VAC and 26.4 VAC.

  • How many switching output channels are provided by the H8PS-8BP positioner?

    The hardware provides 8 discrete PNP open-collector transistor outputs to drive control loads based on angular position.

  • How is the absolute encoder direction changed during commission setup?

    Encoder counting direction for forward (CW) or reverse (CCW) rotation is selected via hardware DIP switches.

  • What display panel interface is used to observe the shaft rotation angle?

    The front panel features a backlit LCD screen that displays real-time shaft angle positions and parameter settings.

  • What form factor size does the front bezel of the housing conform to?

    The enclosure adopts a 1/4 DIN standard form factor, measuring 96 mm wide by 96 mm high with a 67.5 mm depth.

  • Does the H8PS-8BP retain stored angle program settings during power outages?

    Yes, setpoint configurations and parameter limits are saved in non-volatile internal EEPROM without battery reliance.

  • How does I/O density scaling function within the H8PS hardware family?

    System options scale from 8 to 32 outputs to match machine layout needs while sharing standard encoder interface logic.

  • What precautions prevent electrical interference on the encoder input lines?

    Route encoder signal lines inside grounded metal conduits away from variable speed drives and high-current AC lines.
