Product Overview

The General Electric IS220PRTDH1AD is a high-performance Resistance Temperature Device (RTD) input pack designed for the Mark VIe and EX2100e control platforms. This module serves as the primary interface between field-mounted temperature sensors and the controller, providing precision digitization of thermal data. It is engineered to handle multiple RTD inputs, ensuring high-accuracy monitoring of critical parameters such as bearing temperatures, winding temperatures, and process fluid thermal states.

Equipped with dual Ethernet ports for IONet redundancy, the IS220PRTDH1AD facilitates high-speed data acquisition with integrated signal conditioning and linearization. Its robust architecture is specifically tailored for the demanding environments of power generation and heavy industrial control, where electromagnetic interference and thermal stability are primary concerns.

Technical Specifications

• Manufacturer: General Electric (GE)

• Model Number: IS220PRTDH1AD

• Product Series: Mark VIe / EX2100e

• Input Channels: 8 Differential RTD Inputs

• Supported Sensor Types: 10Ω Copper, 100Ω Platinum (DIN/JIS), 120Ω Nickel, 200Ω Platinum

• Communication Protocol: Dual redundant IONet (100 MB Ethernet)

• Scan Rate: Supports high-speed 10ms or 20ms frame rates

• A/D Conversion: 16-bit resolution

• Operating Temperature: -30°C to +65°C (-22°F to +149°F)

• Power Input: 28 VDC nominal

• Dimensions: 13 cm x 8.2 cm x 6 cm

• Weight: 0.36 kg

Core Technical Characteristics

• High-Accuracy Conditioning: The module includes built-in linearization algorithms for various RTD materials, eliminating the need for external signal conversion and reducing the potential for loop errors.

• Network Redundancy: Dual Ethernet ports allow the module to connect to redundant IONet switches, ensuring that temperature data remains available to the controller even in the event of a single network failure.

• Advanced Self-Diagnostics: The IS220PRTDH1AD performs continuous internal self-tests, including hardware monitoring and limit checking for each input channel, with fault reporting delivered directly to the HMI.

• Cold Junction Compensation: While primarily used for RTDs, the internal architecture ensures stable resistance-to-digital conversion across a wide ambient temperature range within the control cabinet.

• Simplified Field Integration: Designed for mounting on a standard terminal board (such as the TRTD series), the module supports a compact footprint while providing high-density I/O for space-constrained enclosures.

Industrial Applications

The GE IS220PRTDH1AD is a foundational component in Distributed Control Systems (DCS) and Excitation Systems, predominantly utilized in:

• Gas and Steam Turbine temperature monitoring

• Generator stator and bearing protection systems

• Large-scale industrial compressor thermal management

• Power plant balance-of-plant (BOP) process control
