Product Overview

The GE IC698CPE020-JX is a flagship central processing unit within the PACSystems RX7i family, engineered for high-end industrial automation and sophisticated control logic. Unlike entry-level controllers, this CPU leverages a VME64-based backplane architecture to provide massive data throughput and deterministic performance. It is specifically designed to handle large-scale applications requiring rapid instruction execution and the management of high-density I/O configurations.

By utilizing a common control engine across the PACSystems portfolio, the IC698CPE020-JX allows for seamless application portability and reduced engineering overhead. This processor is the ideal choice for heavy industrial sectors—including power generation, oil and gas, and complex manufacturing—where high-speed processing and system-wide synchronization are essential for operational safety and efficiency.

Technical Characteristics

• Processing Power: High-speed 1.1 GHz Pentium III-class processor (optimized for 800 MHz execution cycles)

• Memory Capacity: 64 MB of user memory for logic and data, supported by 512 MB of internal RAM

• Operating System: Built on a reliable real-time operating system (RTOS) for deterministic task scheduling

• Communication Ports: Integrated Ethernet interface (10/100 Mbps) with support for SRTP and Modbus TCP/IP protocols

• Backplane Interface: Designed for RX7i VME64 standard, ensuring compatibility with high-speed specialized VME cards

• Programming Support: Fully compatible with Proficy Machine Edition (PME) for ladder logic, structured text, and C-block programming

• Serial Connectivity: Three isolated serial ports for localized monitoring and programming (RS-232 and RS-485)

• Storage: CompactFlash slot for permanent non-volatile storage of user programs and data logs

• Dimensions: 4 x 8 x 29.2 cm

• Weight: 0.8 kg

• Country of Origin: USA

Advanced Performance and Scalability

The IC698CPE020-JX distinguishes itself through its ability to manage thousands of I/O points without degrading cycle times. The integration of 512 MB of memory ensures that even the most memory-intensive algorithms, such as those used in motion control or complex PID loops, run with precision. Its hardware is physically hardened to endure high-vibration and electromagnetically noisy environments, typical of industrial switchgear or engine control rooms.

Connectivity is a core strength of this CPU. With built-in Ethernet and multiple serial interfaces, the module serves as a powerful communication bridge between the plant floor and supervisory DCS/SCADA systems. Furthermore, the inclusion of a CompactFlash slot simplifies field updates and disaster recovery by allowing users to maintain a physical backup of the entire control strategy. This combination of processing speed, expansive memory, and ruggedized hardware ensures that the PACSystems RX7i remains a benchmark for mission-critical automation.
