Product Overview

The GE IC660ELB912G is a high-performance PC Interface Module (PCIM) engineered to integrate personal computer architectures with the proprietary Genius I/O network. Acting as a Micro Genius Printed Wiring Board (PWB), this card enables IBM-compatible PC, AT, and XT systems to serve as controllers or monitoring stations within a Genius bus. By utilizing the robust Genius protocol, the IC660ELB912G ensures deterministic data exchange and high-speed signal processing, making it an essential bridge for legacy system support and modern industrial control upgrades.

Designed for the Mark VIe and Fanuc PLC ecosystems, this Network Interface Card (NIC) provides the hardware layer necessary for complex distributed control. It allows for a streamlined connection between high-level software environments and field-level devices, ensuring that critical process data is managed with minimal latency and maximum integrity.

Technical Characteristics

• Protocol Support: Proprietary Genius Bus Protocol for deterministic industrial communication

• Host Compatibility: Optimized for IBM PC/AT/XT architectures and compatible industrial computers

• Memory Requirement: Reserved 16 Kbyte memory space for efficient signal buffer management

• Device Capacity: Supports a maximum of 30 devices per daughter card connection

• Diagnostic Indicators: Dual onboard LEDs ("GENI OK" and "COMMS OK") for real-time health verification

• System Integration: Primarily used within Mark VIe and Genius I/O distributed architectures

• Hardware Format: Compact Micro Genius PWB (Printed Wiring Board)

• Dimensions: 10.2 x 2.5 x 12.7 cm

• Weight: 0.1 kg

• Manufacturing Origin: USA

Operational Reliability and Networking

The IC660ELB912G distinguishes itself through its simplified diagnostic suite and expansive device-handling capabilities. The dual LED array allows technicians to distinguish between internal board health and network communication status at a glance, significantly accelerating troubleshooting during commissioning or maintenance cycles. This visual feedback is critical in the demanding environments of power generation and heavy manufacturing where the Mark VIe system is frequently deployed.

The card’s ability to manage 30 devices per bus segment allows for extensive decentralization of I/O, reducing the need for expensive, long-run home-run wiring. Its design is hardened against the electrical noise typical of industrial settings, providing a stable platform for PC-based control. Whether implemented in a new automation project or utilized as a direct replacement for an existing Micro Genius interface, the GE IC660ELB912G maintains the high standards of reliability required for mission-critical Distributed Control Systems (DCS).
