Product Overview

The Eaton XV-303-10-C00-A00-1C represents a high-performance convergence of visualization and control logic within a single industrial-grade unit. This 10.1-inch widescreen touch panel features advanced capacitive multi-touch technology, providing an intuitive, smartphone-like user experience for complex machinery interfaces. Engineered for high-speed automation, the XV303 integrates a powerful PLC controller that utilizes CODESYS programming, allowing it to manage complex motion control and data processing tasks simultaneously. Its high-resolution glass display ensures crystal-clear visualization of process parameters even in harsh factory lighting, while the robust hardware architecture facilitates seamless communication with factory-wide networks. This specific unit arrives in mint condition, having undergone rigorous functional testing to guarantee immediate operational readiness for your most demanding control applications.

Core Technical Advantages

Integrated PLC and High-Performance CPU

The XV303 eliminates the need for a separate PLC by embedding high-speed control logic directly into the HMI hardware. The ARM Cortex-A9 processor powers both the graphical interface and the background logic execution, ensuring zero-latency response times during high-speed switching operations. This integration reduces cabinet space requirements and simplifies your overall system architecture.

Multi-Touch Capacitive Technology

The industrial-strength capacitive glass sensor supports multi-touch gestures, allowing operators to zoom into trend graphs or utilize dual-hand safety controls directly on the screen. This scratch-resistant surface withstands aggressive cleaning agents and provides superior visibility compared to traditional resistive screens, maintaining long-term optical clarity.

Extensive Communication Interfaces

Equipped with dual Ethernet ports, CANopen, and RS485 interfaces, the XV-303 acts as a versatile communication hub. It supports modern industrial protocols such as EtherCAT, Modbus TCP, and EtherNet/IP, enabling it to command frequency drives, remote I/O, and sensors across a distributed factory environment without requiring additional gateway modules.

Technical Specifications

Engineering Installation Guide

Power Supply and Connection

Always utilize the provided 24V DC plug for power termination. To ensure stable PLC operation and protect against electrical noise, connect the unit to a stabilized power source and ensure the grounding terminal is properly bonded to the central cabinet earth bar.

Mounting and Environmental Protection

Install the XV303 using the included mounting brackets to achieve the rated IP65 front protection. Ensure the panel cutout matches the 255mm x 160mm dimensions precisely. Avoid installing the unit in direct sunlight or near high-heat components to prevent thermal throttling of the internal CPU.

Peripheral Integration

When connecting to the Ethernet ports, utilize shielded CAT6 cables to maintain signal integrity in high-EMI environments. The integrated SD card slot allows for easy external data logging and program updates; ensure cards are industrial-grade to prevent data corruption during power loss events.

Engineering Advantages

The XV-303-10-C00-A00-1C excels in decentralized automation where space and performance are at a premium. Its fanless design reduces maintenance cycles, as there are no moving parts to fail or filters to clog with industrial dust. The glass front is not only easy to clean but also incredibly durable against the repetitive impact of heavy industrial gloves. By consolidating the HMI and PLC into a single device, you reduce the points of failure and streamline your software development within the CODESYS environment. This unit’s ability to act as both a Modbus master and a web server allows facility managers to monitor machine status remotely through standard mobile devices, bridging the gap between the shop floor and IT infrastructure.

Delivery & Logistics

Delivery Time: 3-5 days once payment is finalized.

Shipping Carriers: Shipped globally via DHL, FEDEX, or UPS.

Packaging: We ship all XV-303 units in anti-static and impact-resistant packaging. As this item is in mint condition and fully tested, it is double-boxed to ensure the screen and housing arrive without a single scratch.

Technical FAQs

Q1: Does this unit include the CODESYS PLC license?

A1: Yes, the XV-303-10-C00-A00-1C comes with the PLC runtime pre-installed and licensed, allowing you to use it as a complete logic controller right out of the box.

Q2: Can I operate this touch screen while wearing industrial gloves?

A2: The advanced capacitive sensor is tuned for industrial use. While it supports multi-touch gestures, it is also responsive to common industrial gloves, ensuring seamless operator interaction.

Q3: What accessories are included with this specific "Mint Condition" item?

A3: This unit includes the necessary mounting brackets for panel installation and the essential 24V DC power connector plug, ensuring you have the hardware needed for immediate setup.

Q4: Is the display readable in bright factory environments?

A4: Yes, the 10.1-inch display features high-contrast LED backlighting and a high-resolution glass surface that minimizes glare compared to plastic resistive screens, ensuring excellent legibility from wide viewing angles.
