E5CC-RX2ADM-800 Omron Digital Temperature Controller E5CC Series
Omron

E5CC-RX2ADM-800 Omron Digital Temperature Controller E5CC Series

SKU: E5CC-RX2ADM-800
Categories : All Products
In Stock
  • Dimensions: 60 mm x 60 mm x 110 mm
  • Country of origin: Japan
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Omron E5CC-RX2ADM-800, also cataloged as the E5CC Digital Temperature Controller, operates as a dedicated hardware component for closed-loop thermal process feedback and relay execution within automated panel networks.

Model Nomenclature & Part Number Breakdown

  • E5CC: Panel-mount standard enclosure series (48 x 48 mm DIN size)
  • RX: Control Output 1 relay output (SPST-NO), Control Output 2 unpopulated
  • 2: 2 auxiliary relay outputs for system alarms or event status signaling
  • A: Operating line power supply option rated for 100 to 240 VAC
  • D: Low-voltage power supply configuration operating on 24 VAC / 24 VDC
  • M: Universal input processing circuit supporting thermocouple, RTD, voltage, and current loops
  • 800: Terminal block option variant designated for standard industrial wiring profiles

Electrical & Operational Specifications

Parameter Specification
Model E5CC-RX2ADM-800
Brand Omron
Origin Japan
Weight 0.13 kg
Shipping Dimensions 60 mm x 60 mm x 110 mm
Operating Temp -10 to 55 deg C
Power Consumption 5.2 VA max. (100-240 VAC) / 3.5 VA max. (24 VAC), 2.5 W max. (24 VDC)
Supply Voltage Rating 100 to 240 VAC (50/60 Hz) or 24 VAC (50/60 Hz) / 24 VDC
Operating Voltage Limits 85% to 110% of rated supply voltage
Control Output 1 Relay output (SPST-NO, 250 VAC, 3 A resistive load)
Linear Output Option 4-20 mA DC / 0-20 mA DC (load 500 ohm max., resolution approx. 10,000)
Input Impedance Current input: 150 ohm max., Voltage input: 1 Mohm min.
Control Method ON/OFF control or 2-PID control with auto-tuning

Network Protocol & Deterministic Execution

The unit integrates internal logic execution supporting firmware flash compatibility for persistent parameter setup without non-volatile data corruption. High-density I/O routing inside the compact housing ensures deterministic response cycles during PID auto-tuning loops, enabling seamless field bus connectivity with programmable logic controller architecture across EtherNet/IP and Profinet networks via industrial interface gateways.

Scope of Delivery & Package Manifest

  • 1 x Omron E5CC-RX2ADM-800 Temperature Controller unit
  • 2 x Panel mounting side brackets
  • 1 x Terminal cover protective shroud
  • 1 x Technical installation guide sheet

Wiring Protocol & Enclosure Installation Guidelines

  • Panel Cutout Mounting

    Cut out a standard 45 x 45 mm square panel opening. Insert the controller housing from the front side and clamp it using the supplied mounting brackets until sealed against the front rubber gasket.

  • Terminal Screw Tightening

    Secure field conductors using M3 crimp terminals. Apply a tightening torque of 0.43 to 0.58 N.m to avoid thread stripping on the rear terminal block.

  • Sensor Signal Wiring

    Route low-level sensor input wiring separately from AC power feeds and motor drive cables. Maintain proper 1:1 direct connection when interfacing with ES2-HB/THB sensors.

Frequently Asked Questions

  • What supply voltage range does the E5CC-RX2ADM-800 controller accept?

    The unit operates on 100 to 240 VAC (50/60 Hz) or 24 VAC / 24 VDC within an allowable operating window of 85% to 110% of rated voltage.

  • What control algorithms are available within the internal microprocessor?

    The controller supports selectable ON/OFF control or 2-PID control modes featuring integrated auto-tuning functionality.

  • What is the maximum load resistance for the linear current output circuit?

    When linear current output is utilized, the unit drives 4-20 mA DC or 0-20 mA DC signals into a maximum load impedance of 500 ohms.

  • What input impedance values apply to analog current and voltage sensors?

    Current input channels exhibit a maximum input impedance of 150 ohms, while voltage input channels present a minimum impedance of 1 Mohm.

  • What primary control switching mechanism is present on Control Output 1?

    Control Output 1 utilizes a electromechanical relay (SPST-NO) rated for 250 VAC at 3 A under pure resistive loads.

  • What connection precaution is required when using ES2-HB/THB humidity/temp sensors?

    When wiring ES2-HB or ES2-THB sensor assemblies to the high-impedance voltage input terminals, a strict 1:1 direct connection topology must be maintained.

  • What resolution does the internal linear analog conversion stage provide?

    The linear current output processing circuit maintains a resolution rating of approximately 10,000 steps across its output span.

  • What is the total unit weight of the physical panel controller?

    The instrument weighs approximately 0.13 kg, making it lightweight for high-density panel DIN cutout installations.
