Product Overview

The Honeywell CV-ADSP01 is a comprehensive HMIWeb Advanced Solution Pack engineered to enhance visualization, alarm management, and real-time data oversight within industrial automation frameworks. This software-based solution is a critical component for Experion LX and PKS systems, providing operators with a high-performance interface to monitor complex plant processes. By integrating sophisticated alarm tracking with modern web-based visualization, the CV-ADSP01 ensures that critical events are identified, prioritized, and addressed with maximum efficiency.

This package includes a single workstation license and the necessary EBR media kit for deployment. Designed to bridge the gap between legacy control data and modern user experience requirements, it empowers plant personnel with deeper operational insights while adhering to strict international standards for safety and alarm management.

Key Technical Characteristics

• Modern Web Technology Integration: Built on a cutting-edge stack utilizing HTML5, WebGL, and React.js, providing a smooth, responsive, and cross-browser compatible user interface.

• High-Throughput Data Handling: Capable of processing up to 50,000 tags per second per client, ensuring that real-time process changes are reflected instantaneously without latency.

• Industry Standard Compliance: Fully adheres to ISA-101.01 and NAMUR NE 148 guidelines, promoting HMI best practices that reduce operator fatigue and improve situational awareness.

• Robust Security Protocols: Features enterprise-grade protection including TLS 1.3 encryption, OPC UA AES-256 standards, and granular role-based access control (RBAC) to secure sensitive operational data.

• Scalable Window Management: Supports up to 16 native display windows per session, allowing operators to oversee multiple process areas simultaneously on high-resolution multi-monitor workstations.

• Advanced Connectivity: Features native support for OPC UA, facilitating seamless communication between various hardware vendors and the central HMI layer.

Technical Specifications

• Manufacturer: Honeywell

• Model Number: CV-ADSP01

• Module Type: Advanced HMI / Alarm Tracker Solution

• License Type: Single Workstation License

• Media Included: EBR Media Kit

• Data Capacity: 50,000 tags/second

• Encryption Standard: AES-256 / TLS 1.3

• System Compatibility: Honeywell Experion LX / PKS

• Weight: 0.4 kg (shipping weight)

• Dimensions: 7 x 14 x 14.5 cm

• HS Code: 8537101190

• Country of Origin: USA

Industrial Application Areas

• Oil and Gas Refining: Centralized monitoring of distillation units and safety-critical alarm tracking.

• Power Generation: Visualization of turbine performance and electrical grid distribution metrics.

• Chemical Processing: Real-time management of batch reactors and complex ingredient dosing systems.

• Pharmaceutical Manufacturing: Ensuring regulatory compliance through precise data logging and alarm audit trails.
