The OMRON CP2E-N30DT1-D, also cataloged as the CP2E-N30 Programmable Controller, is a 30-point DC-powered CPU Unit with 18 digital inputs and 12 sourcing transistor outputs. It belongs to the CP2E-N Network model and operates from a 24 VDC supply.

Model Configuration

The CP2E-N30DT1-D is specifically listed by OMRON as the 30-point 24 VDC CPU with 18 inputs, 12 sourcing transistor outputs, 10K-step program capacity and 16K words of data memory.

Hardware Specifications

OMRON specifies 90 mm x 80 mm x 130 mm for 30-point CP2E CPU Units, with a maximum weight of 580 g. The DC-powered 30/40/60-point CPU group has a maximum system power-consumption rating of 20 W.

PLC Network and Sourcing Output Architecture

The CP2E-N30DT1-D belongs to the N-type Network model. Its N30 configuration provides two Ethernet ports supporting 100BASE-TX and 10BASE-TX communication, with auto-negotiation and auto-sensing. Supported network functions include TCP, UDP, ARP, ICMP ping, SNTP and DNS, with FINS and Socket applications available through the Ethernet interface.

The 12 transistor outputs use a sourcing configuration. This output arrangement should be matched with the electrical commoning and load-side wiring of the connected field devices. It is distinct from the CP2E-N30DT-D, which uses sinking transistor outputs, and the CP2E-N30DR-D, which uses relay outputs.

The N30 CPU configuration supports up to three CP1W-series Expansion I/O Units or Expansion Units. With three 40-point expansion units, the specified maximum I/O capacity is 150 points.

Ordering Information

• 1x OMRON CP2E-N30DT1-D Programmable Controller
• 1x CP2E-N30 30-point CPU Unit
• 18x integrated digital input points
• 12x integrated sourcing transistor output points
• CP1W-series Expansion I/O Units ordered separately when required
• Communication and analog option hardware ordered separately where applicable

Field Installation Guidelines

DC Power Wiring

• Supply the CPU from a 24 VDC source within the specified 20.4 to 26.4 VDC operating range.
• Provide suitable upstream DC protection and isolation.
• Observe DC polarity when wiring the power terminals.
• The DC power supply circuit is not isolated between the primary and secondary DC power supplies.
• Consider the specified 30 A maximum inrush current for 20 ms during cold start when selecting the DC supply and protection devices.

Sourcing Output Wiring

• Confirm that the field load circuit is electrically compatible with sourcing transistor outputs.
• Verify the common wiring arrangement before energizing connected loads.
• Separate output wiring from high-current motor and contactor conductors.
• Use suitable suppression for inductive loads where required by the external circuit.
• Do not interchange sourcing and sinking output wiring without verifying the complete field circuit.

Ethernet Installation

• Use suitable twisted-pair Ethernet cable for the selected transmission speed.
• 100BASE-TX supports Category 5 or higher UTP/STP cabling.
• Keep Ethernet wiring separated from high-energy switching conductors where practical.
• The specified switch-to-node transmission distance is 100 m.

Panel Installation

• Mount the CPU inside the control panel according to the CP2E installation requirements.
• The fixed terminal block uses M3 terminal screws.
• Provide adequate clearance for wiring and thermal dissipation.
• Connect protective grounding to a system ground of 100 ohm or less.

Frequently Asked Questions

• What type of transistor output does CP2E-N30DT1-D use?

  CP2E-N30DT1-D has 12 transistor outputs configured as sourcing outputs. It is electrically different from the N30DT-D sinking-output model.

• What power supply does this CPU require?

  The CPU requires 24 VDC. OMRON specifies an operating voltage range of 20.4 to 26.4 VDC for DC-powered CP2E CPU Units.

• How many I/O points are built into the CPU?

  The N30 CPU has 30 built-in points: 18 digital inputs and 12 transistor outputs. The output circuits use the sourcing configuration.

• What are the physical dimensions of the unit?

  The 30-point CP2E CPU measures 9.0 cm x 8.0 cm x 13.0 cm. OMRON specifies a maximum weight of 580 g for this CPU size.

• How many expansion units can be connected?

  The N30 configuration supports up to three CP1W-series Expansion I/O Units or Expansion Units. The specified maximum system capacity is 150 I/O points.

• Does the N30 CPU have built-in Ethernet?

  Yes. N30 CPU Units provide two Ethernet ports supporting 10BASE-TX and 100BASE-TX. The specified switch-to-node distance is 100 m.

• What high-speed counter capability is available?

  N30/40/60 CP2E CPUs support up to three 100 kHz incremental pulse counters, two 100 kHz up/down counters, or two 100 kHz pulse-and-direction counters, subject to configuration.

• Can this model generate high-speed pulse outputs?

  Yes. Transistor-output N30/40/60 models support up to four pulse outputs with frequencies from 1 Hz to 100 kHz. Pulse output is not available on relay-output models.
