Product Overview

The Honeywell CC-TAIM01 is a high-density Low-Level Analog Input Multiplexer (MUX) designed for the Experion PKS Series C and IOTA-based hardware platforms. Engineered to handle massive signal counts in a compact footprint, this module facilitates the consolidation of up to 64 fully isolated analog input channels. It serves as a specialized data acquisition front-end, primarily used to interface with low-voltage transducers and sensors that require high precision and rigorous electrical separation.

By utilizing a multiplexed architecture, the CC-TAIM01 significantly reduces the physical space required for large-scale I/O subsystems. It is a critical component for industrial facilities that monitor a high volume of temperature, pressure, or low-level voltage points, providing a streamlined path for signal integration into the Distributed Control System (DCS) without sacrificing signal purity or system safety.

Key Technical Characteristics

• Extreme Channel Density: Supports 64 independent low-level analog input channels in a single assembly, drastically lowering cabinet hardware costs and wiring complexity.

• High-Speed Data Sampling: Features a rapid scan rate of 64 channels per second, ensuring that all field data points are refreshed within a one-second window for real-time monitoring.

• Comprehensive Galvanic Isolation: Employs advanced channel-to-channel and channel-to-system isolation barriers, eliminating the risk of ground loops and signal crosstalk.

• Superior Signal Fidelity: Designed with low-noise circuitry to prevent electromagnetic interference (EMI) from distorting sensitive low-level voltage inputs.

• Enhanced Fault Tolerance: The isolated architecture ensures that a sensor failure or electrical surge on one terminal does not propagate to adjacent channels or the backplane.

• IOTA Integration: Designed for seamless mounting on Series C Input Output Termination Assemblies (IOTA), supporting "hot-swap" capability for uninterrupted process operations.

• Precision Acquisition: Optimized for low-level millivolt and transducer signals, providing the high resolution required for accurate process variable calculations.

Technical Specifications

• Manufacturer: HONEYWELL

• Model Number: CC-TAIM01

• Module Type: Low-Level Analog Input Multiplexer

• Channel Count: 64 Fully Isolated Channels

• Scanning Rate: 64 Channels / Second

• Isolation Rating: Comprehensive Channel-to-Channel & Channel-to-System

• System Series: Experion PKS / Series C IOTA

• Condition: Brand New

• Weight: 0.4kg

• Dimensions: 7 x 14 x 14.5 cm

• HS CODE: 8537101190

• Product Origin: USA

Industrial Application Areas

• Temperature Monitoring Arrays: Consolidating hundreds of thermocouple or RTD signals in large-scale furnace or reactor monitoring.

• Refining & Petrochemical: Managing high-density sensor grids for distillation columns and storage tank farms.

• Power Generation: Interfacing with vibration and thermal transducers on large turbine-generator sets.

• Metals & Mining: Monitoring low-voltage sensors in harsh, electrically noisy smelting and processing environments.
