Product Overview

The Honeywell CC-PAON01 is a high-performance Analog Output (AO) module designed for the Experion PKS (Process Knowledge System) architecture. As a core component of the Series C I/O family, this module is responsible for converting digital control commands from the C300 controller into precise electrical signals—typically 4-20mA—to drive field instruments. It serves as the primary interface for modulating final control elements, ensuring that process variables are maintained with high resolution and minimal drift. Engineered for high-availability environments, the CC-PAON01 provides the ruggedized reliability required for continuous industrial operations.

Physical and Electrical Specifications

• Model Identification: CC-PAON01

• Module Type: Analog Output (Non-HART)

• Input/Output Density: 16-Channel Output

• Operating System: Experion PKS / DCS

• Chassis Dimensions: 14.5cm x 5.5cm x 14.5cm

• Net Weight: 0.3 kg

• Mounting Configuration: Vertical Series C I/O Termination Assembly (IOTA)

• Signal Range: Standard 4-20 mA current loop

• On-board Intelligence: Integrated channel-level diagnostics and fault detection

• Country of Origin: USA

Industrial Utility and Deployment

In Pharmaceutical and Fine Chemical Production, the CC-PAON01 is utilized to regulate sensitive batch parameters. By providing stable control signals to variable speed drives and precision dosing valves, it ensures consistent product quality and adherence to strict regulatory standards. The module’s high-fidelity output is essential for maintaining the exact temperature and pressure profiles required during complex chemical synthesis.

Within Oil and Gas Refining, this analog module manages the positioning of critical control valves across distillation units. Its robust design allows it to function reliably in the presence of the electromagnetic interference (EMI) common in heavy industrial facilities. The built-in diagnostic suite enables maintenance teams to monitor loop health in real-time, identifying field wiring issues or actuator failures before they impact production uptime.

For Water Treatment and Utility Management, the CC-PAON01 facilitates the efficient modulation of high-capacity pumps and aeration blowers. Its compatibility with the Series C redundant architecture ensures that even in the event of a controller switchover, the analog outputs remain steady, preventing process surges. The compact, vertical form factor allows facilities to scale their I/O density within existing cabinet footprints, making it a cost-effective solution for both system expansions and legacy hardware refreshes.
