Bently Nevada 3500/93 135785-01 System Display Module 3500 Series
Bently Nevada 3500/93 135785-01 System Display Module 3500 Series
Bently Nevada 3500/93 135785-01 System Display Module 3500 Series
Bently Nevada

Bently Nevada 3500/93 135785-01 System Display Module 3500 Series

SKU: 135785-01
Categories : All Products
In Stock
  • Dimensions: 16x9.5x23cm
  • Country of origin: USA
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Bently Nevada 3500/93 135785-01, also cataloged as the 3500/93 135785-01 System Display Module, operates as a dedicated hardware component for local visualization and annunciation of rack-level machine protection and condition monitoring data within 3500 Series machinery protection system platforms.

Model Identification Data

The 3500/93 135785-01 serves as a localized human-machine interface (HMI) for the 3500 rack. The part number 135785-01 identifies the specific hardware iteration designed for panel-mount integration, providing status updates on input modules and alarm events processed by the rack's internal backplane bus.

Hardware Specifications

Parameter Specification
Model 3500/93 135785-01
Brand Bently Nevada
Origin USA
Weight 1.4 kg
Shipping Dimensions 16 x 9.5 x 21.3 cm
Operating Temp -30 deg C to +65 deg C
Power Consumption 5.5 W (typical)
Communication Proprietary Rack Bus

Rotor Dynamics and TSI Integration

The 3500/93 display module interfaces directly with the 3500 rack backplane to pull data derived from eddy-current probe inputs. While the module does not perform primary signal conditioning, it provides the visualization necessary to validate gap voltage targets, typically checked at -10 VDC for standard probes. The module supports real-time monitoring of rotor dynamics, including vibration amplitudes and shaft centerline positions, ensuring that operators can verify rotor response metrics without direct connection to the host configuration software. Effective cross-talk suppression in the associated input modules is visually confirmed via the display's alarm and OK status indicators.

Ordering Information

  • 3500/93 135785-01 System Display Module

  • Panel mounting gasket and hardware kit

  • User documentation and configuration setup guide

Field Installation Guidelines

  • Panel Cutout: Ensure the cabinet panel cutout adheres to the dimensions specified in the installation drawing to maintain seal integrity.

  • Mounting: Secure the module using the included hardware to ensure a vibration-resistant connection to the control panel.

  • Backplane Seating: Fully insert the module into the designated slot in the 3500 rack until the lever-actuated connector engages with the backplane.

  • Cabling: Use appropriate strain relief for any external interface cables connected to the rear of the module to prevent backplane stress.

  • Grounding: Verify that the 3500 rack chassis is properly bonded to the control system common ground to prevent noise interference with display data.

Frequently Asked Questions

  • Q: Can this module be hot-swapped while the 3500 rack is powered?

    A: Yes, the 3500/93 is designed for removal and insertion under power, provided the rack backplane is secured.

  • Q: Does this module require internal configuration via software?

    A: Yes, the display must be configured using the 3500 Rack Configuration Software to define which rack slots and data points are mapped to the display.

  • Q: What is the purpose of the alarm LEDs on the display?

    A: The LEDs mirror the alarm status of the individual monitoring modules within the rack for immediate visual annunciation of fault conditions.

  • Q: Is this display compatible with all 3500 rack versions?

    A: Compatibility depends on the rack's firmware and backplane revision; verify support in the system configuration software.

  • Q: Does the module support touch input?

    A: The 3500/93 is primarily a display and annunciation unit and does not typically support touch-based control inputs.

  • Q: Can I connect multiple 3500/93 modules to one rack?

    A: Yes, the system architecture supports the installation of multiple display modules to provide information at different physical locations.

  • Q: How are communication errors reported on the display?

    A: Loss of communication with the rack backplane is indicated by a specific "Comm" or "OK" LED fault status on the display face.

  • Q: Does the display retain data during power failure?

    A: The module does not store historical trend data locally; it displays real-time data provided by the rack’s monitoring modules.
