Configured for radial vibration and axial position displacement measurements in 3300 System machinery monitoring platforms, the Bently Nevada 137479-038-10-02 (137479 Dual Probe Transducer) provides direct physical/electrical execution. The instrument converts the mechanical gap spacing between the dual sensor tips and a rotating shaft into proportional analog signals, using independent tracking channels to interface with continuous machinery monitoring systems.

Hardware Part Number Structure

• 137479: Base model designation for the dual probe proximity transducer assembly.

• 038: Full-scale measurement range and mechanical configuration variant selector.

• 10: Standard 5.0 meter (16.4 feet) integrated shielded electrical cable option.

• 02: Hardware termination layout optimized for direct differential industrial connection blocks.

Hardware Specifications

Machinery Monitoring & TSI Metrics

The dual sensor design relies on accurate eddy-current probe scaling to ensure synchronous tracking across both measurement axes during high-speed shaft rotation. Field engineers verify channel health by performing gap voltage validation protocols, ensuring the base voltage outputs fall within the standard -10 VDC targets window when the rotor is at rest. The proximity hardware architecture records dynamic rotor dynamics parameters while internal path shields isolate the sensor elements, maintaining high cross-talk suppression between the dual operational loops.

Logistics Manifest

• 1 * 137479-038-10-02 Dual Probe Transducer Assembly

• 2 * Silicon Terminal Connector Insulator Sleeves

Mechanical and Electrical Grounding Matrix

Rigid Housing Alignment and Mechanical Seating

• Mount the transducer body into the targeted tracking block, ensuring a minimum of 5 full threads of engagement to secure the device under high vibration load.

• Position the dual probe tip faces parallel to the shaft surface, maintaining the designated clearance gap to protect the coils from mechanical contact during thermal growth.

Signal Cable Path and External Shield Termination

• Route the 5.0 meter integrated shielded cable inside grounded metal conduits to isolate the small analog signals from high-voltage supply lines.

• Terminate the outer braid shielding wire at a single point on the monitor cabinet ground rail, ensuring the field sensor tip remains isolated from structural machinery ground loops.

Frequently Asked Questions

• Can the transducer signal lines be hot-swapped while the 3300 monitor rack remains energized?

  Yes, the electrical layout permits hot-swap disconnection and rewiring without causing transient trip hazards or damaging host system components.

• What problem occurs if the target shaft area exhibits localized surface out-of-roundness or electrical runout?

  Surface irregularities distort the eddy-current probe scaling parameters, generating false vibration components that degrade monitor accuracy.

• How is field gap voltage validation verified on this dual-channel transducer model?

  Technicians measure the DC output voltage from each independent channel to check if it matches the calibrated mid-scale bias level.

• What is the response latency of the voltage output loops during sudden changes in rotor dynamics?

  The internal analog circuit responds instantly, tracking dynamic displacement shifts with negligible phase delay up to the frequency limit.

• How does the system architecture achieve effective cross-talk suppression between the closely coupled dual probes?

  The driver loops use staggered frequency modulation parameters to prevent the adjacent electromagnetic fields from causing signal interference.

• Does this device require an external power supply to drive its internal voltage-to-current converter stages?

  Yes, the system must receive a stable -18 V to -24 V DC power loop from the connected machinery monitoring monitor rack.

• What happens to measurement accuracy if the integrated 5.0 meter cable is cut or spliced in the field?

  Splicing changes the loop impedance parameters, which invalidates the factory sensitivity calibration of 200 mV/mil.

• How should the transducer assembly be protected when operating in environments with persistent fluid mist?

  The unit must be enclosed in an oil-tight conduit system to prevent moisture ingress into the rear cable transition joint.
