Product Overview

The ATV610D90N4 is a high-performance frequency inverter belonging to the Schneider Electric Easy Altivar 610 family. Engineered specifically for three-phase asynchronous motors, this 90 kW drive is designed to optimize process efficiency while reducing operational complexity. It serves as a robust solution for managing torque and speed in demanding industrial environments, featuring factory-configured settings that allow for immediate out-of-the-box commissioning. By integrating advanced motor control algorithms, the unit ensures stable performance even under fluctuating load conditions, providing a reliable interface between the power grid and critical rotating equipment.

Core Specifications and Physical Hardware

This module is built to withstand rigorous industrial duty cycles, balancing high power output with a compact physical footprint. The internal architecture includes integrated EMC filters to mitigate electromagnetic interference, ensuring the drive meets stringent global compliance standards for industrial environments.

• Manufacturer: Schneider Electric

• Model Identification: ATV610D90N4

• Power Rating: 90 kW (125 HP)

• Input Voltage: 380V to 415V AC (3-Phase)

• Product Net Weight: 1.9 kg

• Physical Dimensions: 27.9 x 21.6 x 6.3 cm

• Communication Protocol: Modbus RTU (Standard) / Ethernet options available

• Cooling Method: Forced convection for thermal stability

• Protection Rating: IP20 (Standard enclosure)

• Overload Capacity: Designed for 110% to 120% for 60 seconds (Normal Duty)

Strategic Industrial Applications

The ATV610D90N4 is specifically optimized for applications requiring variable torque and high energy savings. Its firmware is tailored to enhance the lifespan of mechanical components by reducing water hammer effects and mechanical stress during start-up.

• Water and Wastewater: Submersible pumps, centrifugal pumps, and lifting stations requiring precise flow control.

• HVAC Systems: Large-scale industrial fans, air handling units (AHU), and cooling tower management.

• Process Industry: Agitators, mixers, and conveyor systems where soft-start and controlled deceleration are mandatory.

• Oil and Gas: Management of auxiliary pumping units and fluid transfer systems.
