Product Overview

The Allen Bradley 80190-380-01-R is a high-performance Drive Control Board (DCB) and Analog Control module designed specifically for the PLC-5 system architecture. This module serves as a critical interface for complex motor control and signal processing within Rockwell Automation's legacy industrial frameworks. It provides the high-speed processing necessary to manage real-time analog data and execute precise control loops in heavy-duty manufacturing environments.

Constructed as a printed circuit board assembly, the 80190-380-01-R integrates directly into specialized drive cabinets or PLC racks. It is engineered to handle the conversion and regulation of signals required for variable speed drives and high-torque motor applications. Despite its legacy nature, this module remains a vital component for facilities looking to maintain or repair existing PLC-5 based automation systems without a full-scale migration to newer platforms.

Technical Characteristics

• Analog Signal Processing: Optimized for high-resolution handling of analog inputs and outputs, ensuring smooth control transitions for motors and actuators.

• Industrial Hardening: The board is manufactured with high-tolerance components to resist the effects of electrical noise (EMI) and thermal stress common in factory floor environments.

• Real-Time Logic Execution: Features specialized circuitry for low-latency command processing, making it suitable for high-speed assembly and synchronized motion tasks.

• Legacy Compatibility: Specifically designed to be backward compatible with PLC-5 series racks and drive control assemblies, facilitating easy "drop-in" replacement for failed units.

• Onboard Diagnostics: Includes hardware-level status verification points to assist maintenance personnel in rapid fault isolation and system health monitoring.

Specifications

• Manufacturer: Allen Bradley (Rockwell Automation)

• Model Number: 80190-380-01-R

• Module Type: Analog Control Board / DCB Assembly

• Product Series: PLC-5 System

• Weight: 0.32 kg

• Dimensions: 25.2 x 19.0 x 2.7 cm

• HS Code: 8537101190

• Origin: USA

• Condition: Brand New (Original Surplus)

• System Architecture: Programmable Logic Controller (PLC)

Application Field

The 80190-380-01-R module is predominantly found in large-scale industrial sectors that utilize legacy Rockwell control systems, including:

• Automotive body shop welding and assembly lines.

• Pharmaceutical batching and mixing processes.

• Food and beverage high-speed bottling and packaging.

• Metal and mining conveyor and drive regulation.
