Product Overview

The Allen-Bradley 2711P-RDT7CM is a high-performance 6.5-inch color display module designed specifically as a functional replacement or upgrade component for the PanelView Plus 700 terminal series. This module serves as the primary visual and tactile interface for industrial operators, featuring an active-matrix TFT (Thin Film Transistor) screen that provides vibrant 18-bit color graphics. Engineered to mount directly onto a logic module, the 2711P-RDT7CM enables clear, real-time visualization of machine data and process control parameters. Its modular design allows for cost-effective maintenance, enabling users to replace the display interface without discarding the entire HMI assembly or losing existing application logic.

Technical Characteristics

The 2711P-RDT7CM is built to maintain operational continuity in demanding industrial environments:

High-Resolution Visual Interface The 6.5-inch screen delivers a resolution of 640 x 480 pixels, optimized for the FactoryTalk View Machine Edition (ME) runtime environment. The active-matrix technology ensures high brightness and a wide viewing angle, which is critical for operators monitoring equipment from various positions on the factory floor.

Robust Touch Response Equipped with an analog resistive touchscreen, the module provides a durable surface capable of being operated by gloved hands, pens, or styluses. The touch interface is designed for high-frequency use, ensuring a long service life even in repetitive manufacturing cycles.

Industrial Grade Protection When properly installed in a NEMA or IP-rated enclosure, the front bezel of the 2711P-RDT7CM maintains an IP65/NEMA 4X rating. This ensures the internal electronics are shielded from moisture, dust, and corrosive chemicals, making it suitable for sectors such as chemical processing and heavy manufacturing.

Field-Replaceable Modular Design As a dedicated display component, the 2711P-RDT7CM features standardized connectors for seamless coupling with PanelView Plus 700 logic modules. This modularity facilitates rapid field repairs, significantly reducing the Mean Time to Repair (MTTR) for critical HMI stations.

Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation

• Model Number: 2711P-RDT7CM

• Product Type: HMI Display Module

• Series: PanelView Plus 700

• Display Size: 6.5-inch

• Display Type: Color Active Matrix TFT

• Resolution: 640 x 480 VGA

• Touchscreen: Analog Resistive

• Backlight: CCFL (Cold Cathode Fluorescent Lamp)

• Enclosure Rating: IP65, NEMA 4X (Front Bezel)

• Operating Temp: 0°C to 55°C (32°F to 131°F)

• Weight: 5.1 kg (Shipping weight)

• Dimensions: 42 x 50 x 18.5 cm

Application Areas

The 2711P-RDT7CM is a vital component for maintaining operator interfaces in several industries:

• Automotive: Real-time status monitoring for assembly line robotics.

• Food & Beverage: Control interfaces for wash-down sensitive packaging equipment.

• Oil & Gas: Visualizing pressure and flow data on localized control panels.

• Pharmaceuticals: Managing clean-room compatible HMI stations for batch processing.
