Configured for managed Ethernet communication in Stratix industrial network systems, the Allen-Bradley 1783-EMS08T (1783-EMS08T Managed Ethernet Switch) provides direct physical network switching execution for EtherNet/IP and TCP/IP communication environments.

Model Identification

The 1783-EMS08T is an Allen-Bradley Stratix Ethernet switch with 8 copper ports and optional fiber optic connectivity. It supports managed network functions including VLAN-related industrial communication management, DHCP, BOOTP, FTP, HTTP, Telnet, IGMP, SMTP, and EtherNet/IP protocol communication.

Hardware Specifications

EtherNet/IP Network Characteristics

The 1783-EMS08T operates as a managed Ethernet communication device within Allen-Bradley industrial control networks. The switch supports EtherNet/IP deterministic communication requirements through managed switching functions and protocol handling.

The Stratix platform provides compatibility considerations for PLC-based Ethernet architectures, allowing communication paths between ControlLogix, CompactLogix, PLC-5 migration systems, and industrial Ethernet devices.

Network configuration functions include TCP/IP addressing services, DHCP and BOOTP assignment, IGMP support for multicast traffic management, and HTTP/Telnet access for switch configuration.

Ordering Information

• 1 x Allen-Bradley 1783-EMS08T Managed Ethernet Switch
• 1 x Industrial Ethernet switch hardware assembly
• 1 x Fiber optic transceiver support interface (optional, if configured)
• No PLC processor, I/O module, or communication cable is included unless specified separately

Field Installation Guidelines

Power Connection

• Verify the supply voltage is within the specified 12 to 48 VDC input range.
• Use appropriate industrial DC power wiring practices for Class 2 / SELV circuits.
• Confirm polarity before energizing the switch.

Ethernet Wiring

• Use compatible industrial Ethernet cables for 10/100 Mbps communication.
• Separate communication wiring from high-voltage power conductors to reduce electrical interference.
• Confirm connector condition before network commissioning.

Configuration Setup

• Assign valid IP parameters before connecting the switch to an active industrial network.
• Verify EtherNet/IP communication paths after network configuration.
• Check status indicators during startup and troubleshooting.

Frequently Asked Questions

• What network protocols are supported by the 1783-EMS08T?

  The switch supports TCP/IP, EtherNet/IP, Telnet, HTTP, DHCP, BOOTP, FTP, IGMP, and SMTP communication protocols.

• How many Ethernet ports are available?

  The module provides 8 copper Ethernet ports and supports 1 optional fiber optic transceiver interface.

• What voltage range is required for operation?

  The switch accepts 12 to 48 VDC input power and operates with a 24 VDC nominal supply requirement.

• Does the 1783-EMS08T support EtherNet/IP networks?

  Yes. The module is designed for managed industrial Ethernet communication using EtherNet/IP protocol environments.

• What is the maximum communication speed?

  The Ethernet interface supports 10/100 Mbps transmission speeds.

• Is fiber communication supported?

  Fiber communication is supported through an optional 1 Gigabit fiber optic transceiver configuration.

• Can the switch be used with PLC systems?

  Yes. It is compatible with Allen-Bradley industrial Ethernet architectures connected to PLC and automation systems.

• What indicators are available for diagnostics?

  The switch provides 16 port indicators and 3 system status indicators for network and hardware monitoring.
