The Allen-Bradley 1747-KE, also cataloged as the 1747-KE Interface Module, operates as a dedicated hardware component for serial communication conversion between DH-485 and DF1 networks within SLC 500 control systems.

Model Identification

The 1747-KE module provides three communication ports consisting of one DH-485 port, one DF1 port, and configuration interfaces. The module supports serial data exchange between SLC 500 processors and external devices requiring DF1 communication.

Hardware Specifications

EtherNet/IP and Serial Network Integration

The Allen-Bradley SLC 500 platform uses defined communication paths between processor units and interface modules. The 1747-KE provides serial communication handling through DH-485 and DF1 protocols, allowing connected devices to exchange controller data through configured communication channels.

The module operates as a protocol interface component rather than an independent controller. Configuration parameters define the communication behavior between the connected SLC 500 processor and external serial equipment.

Ordering Information

• 1 x Allen-Bradley 1747-KE Interface Module
• 1 x Factory-installed communication interface assembly
• Compatible accessories must be selected separately according to system requirements
• User configuration software and programming cables are not included unless specified separately

Installation Guidelines

Mounting and Wiring

• Install the module according to SLC 500 chassis installation requirements.
• Verify backplane connection alignment before inserting the module.
• Remove power from the chassis before module installation or removal.
• Separate communication wiring from high-voltage power conductors to reduce electrical interference.
• Use appropriate shield grounding practices for serial communication cables.

Communication Setup

• Configure DH-485 and DF1 parameters according to connected device requirements.
• Confirm baud rate, node addressing, and communication settings before operation.
• Verify cable termination and connector wiring before applying power.
• Avoid connecting incompatible communication protocols without proper configuration.

Frequently Asked Questions

• What communication protocols does the 1747-KE support?

The module supports DH-485 and DF1 serial communication interfaces for SLC 500 system communication and external device connections.

• How many communication ports are available on the 1747-KE?

The module provides three ports consisting of one DH-485 port, one DF1 port, and one configuration port.

• What power supply range is required for the 1747-KE?

The module operates with a 5 - 24 VDC power input range as specified for the interface module.

• Can the 1747-KE function as an SLC 500 processor?

No. The 1747-KE is a communication interface module and does not execute PLC control logic.

• Is the 1747-KE installed in an SLC 500 chassis slot?

Yes. The module is designed for integration within the SLC 500 hardware environment.

• Does the module require configuration before communication?

Yes. DH-485 and DF1 communication parameters must be configured according to the connected system requirements.

• Can the module directly convert all industrial protocols?

No. The module is designed specifically for supported DH-485 and DF1 communication functions.

• What should be checked before replacing an existing 1747-KE module?

Verify communication settings, wiring connections, power requirements, and compatibility with the existing SLC 500 configuration.
