Product Overview

The ABB DSPB120, designated by part number 573400001-T/3, is a high-tier display processor module engineered for the visualization and control layers of industrial automation systems. Functioning as a specialized graphics and logic engine, this module acts as a bridge between raw process data and the Human-Machine Interface (HMI). It is specifically designed to drive multiple display interfaces with high-resolution output, ensuring that operators in control room environments have access to real-time, high-fidelity process telemetry.

By offloading graphical rendering and interface logic from the main control processor, the DSPB120 maintains system-wide deterministic performance. Its architecture is optimized for simultaneous data handling across various screens, which is essential for complex Distributed Control System (DCS) environments where comprehensive process visibility is required to manage critical industrial workflows.

High-Resolution Graphics and Performance

The technical core of the 573400001-T/3 focuses on rapid data refresh rates and high-definition visualization. This capability is vital for monitoring intricate robotic movements or high-speed manufacturing processes where visual lag can lead to operational errors. The module supports customizable configuration, allowing system integrators to tailor display layouts and navigation paths to the specific ergonomic and safety requirements of a facility.

Built for long-term stability in demanding industrial sectors, the DSPB120 board features a robust circuit design that resists thermal stress and electromagnetic interference. As a central component in the ABB control ecosystem, it facilitates a seamless connection between automated machinery and human operators, reducing training overhead through intuitive interface support while maximizing the computational throughput of modern visualization tasks.

Technical Specifications

• Model Identification: DSPB120

• Order Number: 573400001-T/3

• Module Type: Display Processor / Graphics Control Board

• Manufacturing Origin: Sweden

• Weight: 1.22 kg

• Chassis Dimensions: 24 x 19 x 5.3 cm

• HS Code: 8537101190

• System Integration: ABB DCS / Robotic Control Systems

• Interface Support: Multi-display High-Resolution Output

• Communication: Optimized for real-time Ethernet routing

• Operational Status: Active

Industrial Implementation

• Central Control Rooms: Managing multi-screen arrays for plant-wide process monitoring.

• Robotic Workcells: Driving the display units for high-precision robotic assembly and movement tracking.

• Energy Management: Visualizing complex electrical grids and power distribution metrics in real-time.

• HMI Upgrades: Enhancing older automation systems with modern, high-resolution graphical capabilities.
