The ABB DSQC679 3HAC028357-001, also cataloged as the DSQC679 Teach Pendant, operates as a dedicated hardware component for manual axis jogging, trajectory programming, and real-time motion control execution within ABB IRC5 robot controller networks.

Hardware Identification & Configuration Matrix

• Primary Hardware Model: DSQC679
• Base Reference Model: DSQC-679
• Spare Part Number: 3HAC028357-001
• Product Classification: Operator Interface / Teach Pendant (FlexPendant)
• Interconnect Interface: Integrated 32.5 ft (approx. 10 m) Cable with 17-Pin Heavy-Duty Connector

Mechanical & Electrical Technical Data

Communication Interface & Firmware Synchronization

The DSQC679 interface device maintains high communication velocity over the controller bus, delivering deterministic operator inputs and trajectory updates to the main processor. Embedded memory architectures preserve full firmware flash compatibility across IRC5 system software versions. This hardware integration allows flexible I/O density scaling and continuous diagnostic feedback without introducing latency to safety control loops.

Assembly Package Structure

• 1 x ABB DSQC679 Teach Pendant Assembly (3HAC028357-001)
• 1 x Integrated 32.5 ft Interface Cable with 17-Pin Connector

Site Integration & Cable Handling Instructions

• Connector Alignment: Align the orientation keyways on the 17-pin round connector before pushing it into the controller socket, then fully tighten the threaded locking ring.
• Cable Strain Relief: Avoid bend radii below 100 mm along the 32.5 ft cable assembly to prevent internal conductor fatigue or shielding degradation.
• Enclosure Protection: Mount the teach pendant on its dedicated wall hanger when not in active use to prevent mechanical shock to the touch screen and housing.
• Hot-Plug Restrictions: Verify that safety chain bypass protocols are observed prior to connecting or disconnecting the teach pendant while controller control circuit power is active.

Engineering FAQ & System Integration Answers

• What specific interface connector is integrated onto the DSQC679 cable assembly?

  The unit features an integrated 32.5 ft (10 m) industrial cable terminated with a 17-pin round bayonet-locking connector.

• Can the DSQC679 teach pendant be hot-swapped during active robot movement?

  Disconnecting the pendant opens the dual-channel hardwired emergency stop circuit, triggering an immediate Category 0 safety stop.

• How is grounding continuity maintained through the 32.5 ft connection cable?

  Shielding braid surrounding internal signal lines connects directly through the metal shell of the 17-pin connector to cabinet earth.

• Does replacing an existing DSQC679 pendant require re-flashing the controller software?

  No, the pendant updates display graphics and parameters directly from host controller memory upon establishing serial bus communication.

• What physical package dimensions are required for site transport and storage?

  The packaged hardware unit requires shipping dimensions measuring 30.0 cm in length, 20.0 cm in width, and 12.5 cm in height.

• What is the total combined weight of the DSQC679 unit including its cable?

  The total weight of the teach pendant assembly and attached 32.5 ft cable is 2.18 kg.

• What safety mechanisms are integrated directly into the DSQC679 hardware body?

  The hardware integrates a dual-circuit three-position enabling device along with a red mushroom-head emergency stop push button.

• What precautions must be taken regarding cable installation near high-voltage lines?

  Route the 32.5 ft pendant cable away from motor power leads and VFD output lines to suppress electromagnetic noise coupling.
