ABB 3HAC057547-003 IRC5 Servo Motor
ABB

ABB 3HAC057547-003 IRC5 Servo Motor

SKU: 3HAC057547-003
Categories : ABB
In Stock
  • Dimensions: 34.5 x 13 x 13.5 cm
  • Country of origin: Sweden
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The ABB 3HAC057547-003, also cataloged as the 3HAC057547-003 Servo Motor, operates as a dedicated hardware component for precise angular motion control and torque generation within motion control systems.

Configuration Characteristics & Electrical Rating

The ABB 3HAC057547-003 is a permanent magnet synchronous AC servo motor configured for 400 V AC 3-phase line operation. It delivers a continuous rated torque of 28 Nm at 1500 rpm, with peak torque capacity reaching 84 Nm under transient overload conditions. The winding profile exhibits a torque constant of 1.8 Nm/A, a back EMF rating of 110 V/krpm, and a line-to-line stator resistance of 0.8 ohm.

Physical & Electro-Mechanical Data

Parameter Specification
Model 3HAC057547-003
Brand ABB
Origin SWEDEN
Weight 15.14 kg
Shipping Dimensions 34.5 x 13 x 13.5 cm
Operating Temp 0 deg C to +40 deg C (derated up to +55 deg C)
Power Consumption 4.5 kW rated power
Rated Torque 28 Nm
Peak Torque 84 Nm
Rated Speed 1500 rpm
Max Speed 5000 rpm
Rated Current 9.5 A (28 A peak)
Operating Voltage 400 V AC, 3-Phase
Rotor Inertia 0.012 kg m2
Tariff Code 8537101190

Drive Integration & Deterministic Control Logic

The servo motor interfaces directly with motion control drives across Profinet / EtherNet/IP deterministic networks to execute high-speed position loops. Integrated winding feedback structures match drive controller firmware flash compatibility profiles, providing real-time current vector alignment and high I/O density scaling for dual-channel encoder feedback processing during fast acceleration dynamics.

Standard Delivery Contents

  • 1 x ABB 3HAC057547-003 AC Servo Motor
  • 1 x Integrated Power and Feedback Cable Connector Kit
  • 1 x Mechanical Installation and Safety Guide

Mounting & Connection Guidelines

  • Isolate all 3-phase 400 V AC drive outputs and auxiliary power sources before handling motor connections or shaft alignment.
  • Secure the motor frame to the mounting flange using rated high-tensile bolts, maintaining precise coaxial alignment to prevent radial bearing wear.
  • Connect motor power and feedback wiring using shielded multi-conductor cables to suppress electromagnetic radiation.
  • Terminate shield braid connections across 360-degree ground clamps at both the drive panel and motor connector housing.
  • Verify ambient operating temperatures remain between 0 deg C and +40 deg C to maintain thermal rating without current derating.

Technical Engineering FAQ

  • What is the continuous rated power and speed rating for the 3HAC057547-003?

    The motor delivers a continuous rated power output of 4.5 kW at a base rated speed of 1500 rpm under nominal 400 V AC power input.

  • What peak current levels can the stator windings tolerate?

    The motor winding tolerates a peak current of 28 A, providing transient peak torque generation up to 84 Nm.

  • What type of operating voltage is required for the motor power circuit?

    The motor requires a 400 V AC 3-phase supply delivered through a compatible variable frequency servo drive unit.

  • How does ambient operating temperature affect motor output rating?

    Full continuous torque is available from 0 deg C to +40 deg C; operation up to +55 deg C requires current and torque derating.

  • What is the line-to-line winding resistance value for testing?

    The stator winding exhibits a line-to-line electrical resistance of 0.8 ohm when measured at ambient conditions.

  • What is the rotor moment of inertia specification?

    The mechanical rotor structure features a calculated moment of inertia equal to 0.012 kg m2.

  • How is electromagnetic interference prevented in feedback wiring?

    Feedback connections must utilize low-capacitance shielded twisted-pair cabling terminated with full peripheral earth clamps.

  • Does the motor support hot-swapping or live disconnection from the drive?

    No, power connectors must never be removed while the drive is energized due to high voltage back-EMF hazards.
