Configured for discrete digital signal acquisition and internal logic execution in protection and control racks, the ABB 1MRK000167-GCr00 (1MRK000167 Circuit Card) provides direct physical/electrical execution.

Component Designators & Spare Cross-Reference

• 1MRK000167-GCr00: Primary manufacturing catalog number and revision designator.
• 1MRK: Protection and control hardware family platform prefix.
• 1MRK000005-258: Designated spare part cross-reference catalog code.

Physical & Electrical Parameters

System Backplane & Bus Isolation

The circuit card integrates a multi-layer board topology to sustain high backplane bus communication velocity across adjacent protection processing units. Solid-state isolation barriers decouple internal logic from field transients, ensuring firmware flash compatibility and deterministic logic routing across I/O expansion racks.

Standard Equipment Delivery

• 1 x ABB 1MRK000167-GCr00 circuit card
• 1 x Technical terminal mapping and installation document

Hardware Assembly & Wiring Protocols

• Rack Insertion

  Align the 6-layer board edges carefully with card guide rails and seat the rear connector firmly into the backplane bus socket.

• Cable Routing

  Separate 24 VDC digital I/O lines from high-voltage AC control circuits in panel channels to prevent EMI coupling.

• Earthing Connections

  Maintain rigid metal-to-metal grounding contact between the card front panel plate and the subrack chassis frame.

Technical FAQ

• What operating voltage range is supported by the 1MRK000167-GCr00 circuit card?

  The card circuitry accommodates wide auxiliary operating supplies ranging from 24 to 250 VDC/AC.

• What is the typical power consumption of this module under load?

  Power consumption for the assembly typically ranges between 5 W and 10 W depending on active I/O switching states.

• What galvanic isolation rating applies to field input terminals?

  The board incorporates optical and physical isolation barriers rated up to 2 kV AC between logic and field circuits.

• Is hot-swapping permitted for this circuit card inside a energized rack?

  No, power to the rack chassis must be isolated prior to removing or installing the circuit card assembly.

• What is the rated operating temperature range for field deployment?

  The hardware is rated for continuous operation across temperature extremes from -40 deg C to +70 deg C.

• What PCB manufacturing standard is utilized for this module?

  The assembly is built using a high-density 6-layer printed circuit board design with internal ground and power planes.

• How are digital I/O channels rated on the terminal interface?

  The digital input and output interface operates at a nominal rated logic potential of 24 VDC.

• What spare part model replaces the 1MRK000167-GCr00 assembly?

  The manufacturer cross-references spare model catalog number 1MRK000005-258 for field hardware replacement.
