Product Overview

The ABB 1KGT013000R0001, model 23TP22, is a specialized industrial power conversion module engineered for the Advanced Process System and RTU500 series environments. This unit serves as the electrical backbone for mission-critical automation hardware, providing the stabilized voltage necessary for distributed control logic and field communication interfaces. Designed to facilitate the integration of intelligent electronic devices, such as Tmax XT circuit breakers and remote terminal units, the 23TP22 ensures that sensitive microprocessor-based circuitry remains protected from fluctuations in the primary energy source. Its heavy-duty construction is specifically tailored for long-term deployment in power distribution and infrastructure projects where power availability is the primary factor in system uptime.

Hardware Specifications and Engineering Metrics

The 23TP22 1KGT013000R0001 is characterized by a high-mass, thermally efficient design suitable for high-availability DCS architectures:

• Model Number: 23TP22

• Engineering Order Code: 1KGT013000R0001

• Product Category: Power Supply Module

• Chassis Dimensions: 48 x 26.3 x 19.5 cm

• Unit Weight: 2.46 kg

• System Integration: Advanced Process Systems / RTU560 / Tmax XT compatibility

• Functional Reliability: Integrated surge protection and real-time output monitoring

• Thermal Management: Passive convection cooling with high-efficiency heat dissipation

• Physical Mounting: Extension panel and rack-ready configuration

• Tariff Identification: HS Code 8537101190

• Manufacturing Origin: Sweden

Industrial Utility and Deployment Scenarios

In Electrical Grid Automation and Substation Management, the 23TP22 provides the vital DC power required for Remote Terminal Units (RTUs) and intelligent switchgear. By delivering a ripple-free voltage supply, the module ensures that protection relays and circuit breaker controllers can accurately sample line data and execute trip commands without interference. Its robust design is particularly valuable in utility settings where the power supply must withstand the high electromagnetic noise levels associated with high-voltage switching.

Within Continuous Process Control and Manufacturing, this power supply unit acts as a centralized energy source for decentralized I/O racks. The 1KGT013000R0001 is often utilized in chemical plants and refineries to power the communication bus between field sensors and the central DCS. Its high weight and substantial dimensions reflect a design focused on component longevity, allowing the unit to maintain stable operation in 24/7 duty cycles where failure-induced downtime would result in significant financial loss.

For Infrastructure and Smart Grid Monitoring, the 23TP22 supports the real-time telemetry required for modern energy management. It facilitates the seamless connection of monitoring panels to the wider network, ensuring that status data from circuit breakers and meters is consistently available to plant operators. Despite its discontinued status as of late 2018, it remains a critical legacy component for maintaining the operational integrity of existing ABB-based automation frameworks, providing a reliable solution for facility upgrades and system restoration.
