Product Overview

The Bently Nevada 991-25-50-03-05 is a compact, loop-powered signal conditioner engineered specifically for monitoring axial shaft position in rotating machinery. Unlike traditional rack-mounted systems, this 2-wire transmitter integrates Proximitor technology directly into a field-mountable housing. It accepts inputs from 3300 NSv proximity probes and converts the eddy current signal into a standardized 4–20 mA output proportional to thrust displacement. This allows for direct integration with PLCs or DCS control systems, making it an ideal choice for OEMs (Original Equipment Manufacturers) of centrifugal air compressors, high-speed pumps, and industrial fans where space and cost-efficiency are paramount.

Key Technical Characteristics and Hardware Parameters

Designed for high-fidelity signal processing in extreme industrial environments, the 991-25-50-03-05 ensures measurement integrity through the following specifications:

• Model Number 991-25-50-03-05

• Measurement Type Axial Thrust (Static Displacement)

• Linear Range 0.6 mm to 0.6 mm (25-0-25 mils) or 1.0 mm to 1.0 mm (40-0-40 mils) depending on probe configuration

• System Length Calibrated for 5.0 meter (16.4 feet) total system length (Option -50)

• Input Compatibility Specifically designed for 3300 NSv proximity transducers

• Output Signal 4 to 20 mA DC (Industrial standard current loop)

• Diagnostic Interface Non-isolated "PROX OUT" terminal and coaxial connector for raw gap voltage and dynamic signal analysis

• Mounting Configuration 35mm DIN-rail clips and bulkhead mounting (Option -03)

• Electrical Connection 3-pin MIL-C-5015 top-exit connector (Option -05)

• Environmental Protection Potted construction rated for 100% condensing humidity and hazardous area operation

• Safety Logic Integrated "Not OK/Signal Defeat" circuit to prevent false alarms caused by sensor or wiring failure

Industrial Applications and Operational Use Cases

The 991-25-50-03-05 transmitter is a critical component for Turbine Supervisory Instrumentation (TSI) in various heavy-duty industrial sectors:

• Centrifugal Air Compressors Real-time tracking of axial movement to protect against impeller-to-shroud contact during high-load intervals.

• High-Speed Electric Motors Monitoring rotor position in motors equipped with fluid-film bearings to detect thrust bearing degradation.

• Boiler Feed Pumps Providing reliable displacement data in power generation plants where humidity and temperature fluctuate significantly.

• Industrial Fan Assemblies Protecting large-scale cooling and ventilation fans from catastrophic axial failure.

• Hazardous Area Deployment Utilizing its robust, certified design for safe installation in oil and gas refineries and chemical processing facilities.
