3BSE018405R1 ABB TC513V1 Coax/Twisted Pair Modem Advant Fieldbus 100
-
Dimensions: 4.4 × 15 × 17.6 cm
-
Country of origin: Sweden
-
Payment: T/T, Western Union
-
Shipping port: Xiamen
Product Overview
The ABB TC513V1 (order number 3BSE018405R1) is a communication modem for Advant Fieldbus 100 (AF100) networks. It is used to interface and extend fieldbus communication over supported physical media, allowing AF100 segments to be implemented using either twisted pair cabling or 75 Ω coaxial infrastructure where applicable.
This modem is typically installed in DCS communication panels to support reliable data transfer in electrically noisy industrial environments. It is supplied as a spare or replacement part for existing AF100 installations and should be applied according to the site’s AF100 network design rules (segment length, termination, grounding, and shielding).
Hardware Parameters
| Parameter | Value |
|---|---|
| Model / Order Code | TC513V1 / 3BSE018405R1 |
| Product Type | Coax/Twisted Pair Fieldbus Modem |
| Product Family | Advant Fieldbus 100 (AF100) |
| Supported Media | Twisted pair and 75 Ω coax (application dependent) |
| Supply | 24 VDC (typical for AF100 devices) |
| Data Rate | Up to 1.5 Mbps (system dependent) |
| Typical Power | < 5 W |
| Isolation | Rated insulation voltage 50 V (as specified) |
| Condition | Brand New |
| Status | Active |
| Availability | In Stock |
| Origin | Sweden |
| MOQ | 1 |
| Approx. Weight | 0.72 kg |
| Approx. Dimensions | 4.4 × 15 × 17.6 cm |
| HS Code | 8537101190 |
Technical correction note
The text includes mixed and conflicting dimensional statements and references to “Ethernet router,” which is not the function of this modem. UUID/SCIP/WEEE category claims are not required for product function and cannot be verified from the provided header information, so they are omitted.
Installation and integration notes
-
Confirm network topology rules and allowable cable lengths for the specific AF100 segment design.
-
Apply correct termination practices for coax or twisted pair to avoid reflections and intermittent faults.
-
Follow cabinet grounding and shielding practices to maintain EMC robustness.
Industrial Applications
Typical use cases include:
-
AF100 network extensions in legacy ABB DCS installations where long cable runs require controlled physical-layer behavior
-
Replacement of failed modems in existing Advant Fieldbus 100 communication panels to restore segment connectivity
-
Refurbishment projects on ABB legacy fieldbus systems where original media (coax or twisted pair) must be retained
-
Industrial plants running AF100-based control networks in power generation, process industries, pulp & paper, and general manufacturing
Commissioning considerations
-
Verify stable link operation after installation and confirm bus diagnostics from the host system
-
Validate segment performance under load and during cabinet EMI conditions (drive start/stop events, switching operations)
