Product Overview

The SDCS-PIN-4, identified by the manufacturing code 3ADT314100R1001, is a high-performance power interface board designed for the precise regulation of DC drive systems. This PCB card serves as the vital link between the incoming supply and the control electronics, executing critical AC-to-DC rectification and filtration. By utilizing advanced filtering topologies, the 3ADT314100R1001 ensures that sensitive automation components receive a stabilized DC voltage free from the harmonic distortions typically found in heavy industrial power grids. While the manufacturer has transitioned newer installations toward the 3ADT316300R1510 superseding model, this original SDCS-PIN-4 board remains the definitive standard for maintaining the operational integrity of legacy DCS and DC drive architectures.

Engineering Parameters and Technical Attributes

• Core Designation: SDCS-PIN-4

• Order Catalog Number: 3ADT314100R1001

• Primary Function: Power conditioning and signal interfacing for DC converters

• Protection Logic: Integrated EMI suppression to mitigate conducted and radiated noise

• Physical Weight: 1.22 kg (Shipping weight) / 0.8 kg (Net unit weight)

• Form Factor: 24 x 19 x 5.3 cm

• Origin of Production: Sweden

• Regulatory Compliance: Industrial-grade EMC standards for low-noise operation

Industrial Deployment Scenarios

The SDCS-PIN-4 3ADT314100R1001 is predominantly found in sectors where motor control precision and power quality cannot be compromised. Key applications include:

Metals and Mining OperationsThe board is frequently integrated into large-scale DC mill drives and hoist controllers, where it manages the power interface for high-torque motor sequences while protecting logic circuits from massive electrical surges.

Pulp and Paper FacilitiesIn continuous production lines, this interface card provides the stable DC power necessary for synchronized sectional drives, ensuring uniform tension and speed control across the manufacturing process.

Legacy System SustainmentAs a critical spare part for discontinued but active DCS frameworks, the 3ADT314100R1001 allows plant managers to avoid costly full-system overhauls by replacing failed power interface layers with original-specification hardware.

Marine and Heavy LiftingEmployed in offshore winch systems and crane drives, the board’s robust EMI shielding ensures that power conversion does not interfere with sensitive navigation or communication sensors sharing the same power bus.
