Configured for multi-channel thermal data acquisition in industrial machinery monitoring networks, the Bently Nevada 3500/60-01-00 (3500/60-01-00 Temperature Module) executes direct signal processing of RTD and thermocouple inputs across rack backplanes.

Model Suffix Decomposition

• 3500/60: Base model designation for the Temperature Module architecture.
• 01: RTD/TC non-isolated I/O module configuration featuring internal terminations and no recorder outputs.
• 00: Indicates no auxiliary agency approval options beyond standard compliance.

Hardware Specifications

Rotor Dynamics And Thermal Signal Validation

• Input Processing: Accepts between 1 and 6 RTD or thermocouple transducer signals per module to track bearings and casing temperatures.
• Input Impedance: Maintains a high input impedance of 10 Mohm for each lead input to minimize signal loading errors.
• Noise Suppression: Incorporates internal filtering to protect thermal voltage readings against high-frequency electromagnetic interference in industrial environments.
• Data Integration: Synchronizes temperature metrics with vibration parameters across the rack backplane to support comprehensive machinery health evaluations.

Bill Of Delivery

• 1 x 3500/60-01-00 Temperature Module main assembly
• 1 x RTD/TC non-isolated internal termination I/O module

Rack Installation And Wiring Guidelines

• Slot Assignment: Insert the module into any available full-height rear slot within the 3500 rack chassis designated for monitor and I/O pairing.
• Terminal Connections: Wire RTD and thermocouple leads directly to the internal termination points while maintaining correct polarity.
• Shield Grounding: Terminate all sensor signal shields at the designated chassis ground studs to prevent ground loops and noise coupling.
• Power Verification: Confirm backplane power distribution is stable before seating the module to protect internal logic circuits.

Frequently Asked Questions

• Question: What is the primary function of the 3500/60-01-00 module?

  Answer: It processes thermal inputs from RTDs and thermocouples to monitor temperatures in industrial machinery applications.

• Question: How many transducer channels does a single module accept?

  Answer: The unit accepts from 1 to 6 RTD or thermocouple transducer signals.

• Question: What is the input impedance rating for each lead input?

  Answer: Each lead input maintains an input impedance of 10 Mohm.

• Question: Does this module include built-in recorder outputs?

  Answer: No, the 01 configuration option denotes a design without recorder outputs.

• Question: What is the nominal power consumption of the module assembly?

  Answer: The unit draws a nominal power of 9 watts during active operation.

• Question: What physical slot space is required in the rack?

  Answer: It requires 1 full-height rear slot space within the 3500 rack housing.

• Question: What is the specified storage temperature range for the hardware?

  Answer: The storage temperature range spans from -40 deg C to +85 deg C.

• Question: What type of I/O termination is utilized by this specific part number?

  Answer: It uses an RTD/TC non-isolated I/O module configuration with internal terminations.
